Environmental specifications

Space requirements

Printer controller placement

Installation Planning Guide
To reduce the risk of electrical shock, do not plug
components into any other type of power system. Contract
your facilities manager or a qualified electrician if you are
not sure what type of power is supplied to your work area.
The environmental requirements for the DocuPrint NPS/IPS
controller are all satisfied by the printer module. Refer to the
"Printer specifications and requirements" chapter of this guide.
Table 5-2. Heat dissipation specifications for the DocuPrint
NPS/IPS controller
Heat dissipation
Processor/ 1,100 BTU per hour
monitor
HCU 408 BTU per hour
This section provides recommendations for placement of printer
controller hardware components.
For printer component space requirements, refer to the "Printer
specifications and requirements" chapter of this guide. Contact
your service representative if you have questions not specifically
addressed in this guide.
You should consider the following factors when deciding where to
place the DocuPrint printer controller:
• Adequate work space and service clearance around the
equipment
• Proximity to electrical and network connectors
• Security of the work area. You may need to place the system
in an area where you can restrict access to it.
WARNING
5-3
