Installation Planning Guide
2
2
Figure 5-2. Sun Blade 1000 fan and vent locations to keep
clear
1. Vents inside the processor
2. Vents in front and back of processor
Do not:
•
Do not place the controller monitor on top of the processor.
•
Do not allow any piece of equipment to blow warm air into the
air intake vents of the processor.
•
Do not place the processor on its side, or in any other
position but the upright, vertical position.
•
Do not place the processor or monitor on top of the printer.
2
1
5-5
