Installation Planning Guide
The following illustrates a top view of the space requirements for
the printer with a dual feeder and stitcher/stacker configuration.
Figure 6-6. 4635/180 printer with inverter feeder/stacker +
feeder/stacker + feeder/stacker + feeder/stacker
configuration
1. Back of system
2. Inverter
3. Feeder/stacker
4. Feeder/stacker
5. Feeder/stacker
6. Feeder/stacker
7. Front of system
8. Printer
