Installation Planning Guide
1. Processor feeder tray 1
2. Processor feeder tray 2
3. High-capacity feeder tray 3
4. Side 1 of sheet leaving feeder tray
5. Drilled holes (on right edge)
6. Origin 0,0: portrait feeder tray 4
7. High-capacity feeder tray 4
8. Side 1 of sheet leaving feeder tray
9. Drilled holes (on right edge)
10. Origin 0,0: portrait feeder tray 4
11. Inverter
12. Duplex inverter
13. Sample tray
14. Disk inversion
15. High-capacity stacker bin A
16. Side 2 of sheet stacked in bin
17. Drilled holes (on left edge)
18. Origin 0,0: portrait orientation
19. High-capacity stacker bin B
20. Side 2 of sheet stacked in bin
21. Drilled holes (on left edge)
22. Origin 0,0: portrait orientation
23. Purge tray
24. Bypass transport
25. Side 2 of sheet passing through bypass transport
26. Drilled holes (on left edge)
27. Origin 0,0: portrait orientation
3-11
