H2 Stationary GrainGage User's Guide

1. 2. 3 Install the Mesa 3 and Cradle

The Mesa 3 can be mounted on either side of the H2 Stationary GrainGage, but it is recommended that you
mount it on the side with the USB and power cable.
Cradle Mount Bolts
Introduction to the H2 Stationary GrainGage
1. Remove the cradle mount bolts on one side of the
GrainGage. Set aside.
2. Attach the Mesa 3 cradle using the mount bolts.
3. Place the Mesa 3 in the cradle.
4. The Mesa 3 power cable and USB cable extend from a
hole in one side of the GrainGage. Plug them into the
Mesa 3.
Note: Remove the Mesa 3 during transport.
