Ctp2056 Platform Specifications And Certification - Juniper CTP2000 Series Hardware Manual

CTP2056 Platform Specifications and Certification

Table 10: CTP2056 Platform Specifications
Category
Weight
Chassis only
Dimensions
Chassis only
Environmental Requirements
Ambient operating temperature
Ambient operating humidity
DC Input
Voltage
Current
Power
Redundancy (input power)
AC Input
Power required
AC line frequency
Nominal current (115V amps)
Power
Space Requirements
Specification
27 lb (12.25 kg)
7.0 in. (17.8 cm) high
17.25 in. (43.81 cm) wide
11.25 in. (28.57 cm) deep
32° to 104° F (0° to 40° C)
5% to 90% (noncondensing)
–40 to –72 VDC
4A @ –48 VDC
192 W
2 independent line feeds
100–240 VAC
50–60 Hz
2.5
250 W
3 ft. (90 cm) behind device or rack.
Do not block air vents on the front or back of the device.
38
