User-selectable HDCP authorization for DTP2 and HDMI inputs — Allows inputs
•
2 through 6 or 2 through 8 to appear HDCP compliant or non-HDCP compliant to the
connected source, which is beneficial if the source automatically encrypts all content
when connected to an HDCP-compliant device. Protected material is not passed in
non-HDCP mode.
Key Minder continuously verifies HDCP compliance for quick, reliable
•
switching — Key Minder authenticates and maintains continuous HDCP encryption
between input and output devices to ensure quick and reliable switching in professional
AV environments, while enabling simultaneous distribution of a single source signal to
one or more displays.
Comprehensive EDID management — Use PCS software to access EDID Minder for
•
setting video input EDID, capturing EDID from connected displays, or uploading custom
EDID files. Proper EDID management ensures that sources and displays are easily
integrated into a system resulting in optimized system operation. Freely downloadable
EDID Manager 2.0 software is available for advanced EDID editing and creating custom
EDID files.
EDID Minder automatically manages EDID communication between connected
•
devices — EDID Minder ensures that the source powers up properly and reliably
outputs content for display.
•
SpeedSwitch Technology provides exceptional switching speed for
HDCP-encrypted content.
Supports custom EDID and output resolutions — User-defined output resolutions
•
can be supported by uploading custom EDID files, or capturing EDID from a display or
other destination device.
HDCP authentication and signal presence confirmation — Provides real-time
•
verification of HDCP status for each digital video input and output. This allows for
simple, quick, and signal and HDCP verification through RS-232, USB, or Ethernet,
providing feedback to a system operator or helpdesk support staff.
•
HDCP visual confirmation — When HDCP-encrypted content is transmitted to
a non-HDCP compliant display, a full screen green signal is sent to the display for
immediate visual confirmation that protected content cannot be viewed on that display.
•
Aspect ratio control — The aspect ratio of the video output can be controlled by
selecting a FILL mode, which provides a full screen output, or a FOLLOW mode, which
preserves the original aspect ratio of the input signal.
Motion-adaptive deinterlacing for signals up to 1080i — Advanced deinterlacing
•
for all interlaced signals up to 1080i delivers optimized image quality.
•
Automatic 3:2 and 2:2 pulldown detection — Advanced film mode processing
techniques that help maximize image quality for content sources that originated from
film.
•
Auto-Image setup — When activated, the unit automatically optimizes the image by
analyzing and adjusting to the video input signal. This can save time and effort in setting
up a newly connected source, particularly in presentation environments where different
guest presenter laptops with various output resolutions will be connected.
•
Auto Input Memory — When activated, the unit automatically stores size, position,
and picture settings based on the incoming signal. When the same signal is detected
again, these image settings are automatically recalled from memory.
•
Input presets — Memory presets are available to store and recall optimized image
settings.
•
Output muting control — The video and audio output may be muted independently.
IN1806 and IN1808 Series Scaling Presentation Switchers • Introduction
5
