Perform the following steps to change the IP address:
1. From the Create Cluster? option, press the select button. The IP address option
displays.
2. Press the select button again. The first IP address number is highlighted.
3. Press the up button if you want to increase the value that is displayed; press
the down button if you want to decrease that value. If you want to quickly
increase or decrease the value, hold the up or down button, respectively.
4. Press the right or left buttons to move to the number field that you want to
update.
5. Repeat steps 3 and 4 for each number field that you want to update.
6. Press the select button to complete the change.
Press the right button to display the next secondary option or the left button to
display the previous options.
Subnet Mask
This option lets you display or change the subnet mask.
Attention:
If you change the subnet mask address, ensure that you type the
correct address. Otherwise, you cannot access the cluster using the command line
tools or a Web browser.
Perform the following steps to change the subnet mask:
1. Press the select button. The first subnet mask number is displayed.
2. Press the up button if you want to increase the value that is displayed; press
the down button if you want to decrease that value. If you want to quickly
increase or decrease the value, hold the up or down button, respectively.
3. Press the right or left buttons to move to the number field that you want to
update.
4. Repeat steps 2 and 3 for each number field that you want to update.
5. Press the select button to complete the change.
Gateway
Attention:
If you change the gateway address, ensure that you type the correct
address. Otherwise, you cannot access the cluster from the Web interface or
command line.
Perform the following steps to change the gateway address:
1. Press the select button. The first gateway address number field is highlighted.
2. Press the up button if you want to increase the value that is displayed; press
the down button if you want to decrease that value. If you want to quickly
increase or decrease the value, hold the up or down button, respectively.
3. Press the right or left buttons to move to the number field that you want to
update.
4. Repeat steps 2 and 3 for each number field that you want to update.
5. Press the select button to complete the change.
Chapter 4. Using the front panel display on the SAN Volume Controller
67
