DANGER
You have already switched on the UPS 5125. The output sockets of the
UPS 5125 are live.
3. Place the free end of the SAN Volume Controller power cable into any vacant
3
output connector
4. Place the free end of the signal cable into any vacant position on the top row of
4
serial connectors
Attention:
Do not plug any signal cables into the bottom row of signal cable
connectors or the UPS 5125 will malfunction.
The SAN Volume Controller power is connected to the UPS 5125.
Related tasks
"Inspecting the SAN Volume Controller for unsafe conditions" on page xix
Be cautious of potential safety hazards that are not covered in the safety
checks. If unsafe conditions are present, determine how serious the hazards are
and whether you should continue before correcting the problem.
"External machine checks" on page xx
Ensure that you perform an external machine check on the SAN Volume
Controller.
"Internal machine checks" on page xx
Ensure that you perform an internal machine check before installing the SAN
Volume Controller.
"Inspecting the uninterruptible power supply for unsafe conditions" on page xx
Ensure that you take the time to inspect the uninterruptible power supply (UPS)
for unsafe conditions.
Related reference
"Danger notices for the uninterruptible power supply" on page xvi
Ensure that you understand the danger notices for the uninterruptible power
supply (UPS).
"Danger notices for the SAN Volume Controller" on page xvii
Ensure that you are familiar with the danger notices on the SAN Volume
Controller.
"Caution notices for the uninterruptible power supply" on page xvii
Ensure that you understand the caution notices for the uninterruptible power
supply (UPS).
"Caution notices for the SAN Volume Controller" on page xviii
Ensure that you understand the caution notices for the SAN Volume Controller.
"Controls and indicators for the SAN Volume Controller" on page 5
Controls and indicators are located on the front panel of the SAN Volume
Controller.
"SAN Volume Controller rear panel indicators" on page 7
The controls and indicators for the SAN Volume Controller are contained on the
front and back panel assembly.
"Controls and indicators for the uninterruptible power supply 5125" on page 22
All controls for the uninterruptible power supply 5125 are located on the front
panel assembly.
Chapter 3. Installing the uninterruptible power supply and the SAN Volume Controller
on the UPS 5125.
on the UPS 5125.
