3.6 Outline and Installation Drawings

3.000 76.20
.390 9.91
1.831 46.51
CENTER OF GRAVITY
3.780 96.01
190-01115-01
Rev. AA
.277 7.04
6.533 165.93
4.650 118.11
NOTES:
1.
2.
.100 2.54
Figure 3-2 GAD 27 Outline Drawing
G3X/G3X Touch Installation Manual - GAD 27 Installation
DIMENSIONS: INCHES [MM].
DIMENSIONS ARE SHOWN FOR REFERENCE ONLY.
.984 24.99
CENTER OF GRAVITY
3.215 81.66
CENTER OF GRAVITY
4.687 119.05
5.204 132.18
3.569 90.65
1.723 43.77
.040 1.02
TYPICAL THICKNESS
BENEATH FASTENER HEAD
Page 3-4
