Monitoring and Analyzing Switch Operation
Status and Counters Data
B-14
Viewing the Switch's MAC Address Tables
Feature
viewing MAC addresses on all
ports on a specific VLAN
viewing MAC addresses on a
specific port
searching for a MAC address
These features help you to view:
■
The MAC addresses that the switch has learned from network devices
attached to the switch
The port on which each MAC address was learned
■
Menu Access to the MAC Address Views and Searches
Per-VLAN MAC-Address Viewing and Searching. This feature lets you
determine which switch port on a selected VLAN is being used to communi-
cate with a specific device on the network. The per-VLAN listing includes:
■
The MAC addresses that the switch has learned from network devices
attached to the switch
The port on which each MAC address was learned
■
1.
From the Main Menu, select:
1. Status and Counters
5. VLAN Address Table
2.
The switch then prompts you to select a VLAN.
3.
Use the Space bar to select the VLAN you want, then press
switch then displays the MAC address table for that VLAN:
Default
Menu
CLI
n/a
page B-14
page B-17
n/a
page B-16
page B-17
n/a
page B-16
page B-17
Web
—
—
—
[Enter]
. The
