ProCurve 6200yl Management And Configuration Manual page 588

Troubleshooting
Diagnostic Tools
ProCurve(config)# ip dns server-address 10.28.229.10
ProCurve(config)# ip dns domain-name pubs.outdoors.com
Figure C-21. Configuring Switch "A" in Figure20 To Support DNS Resolution
ProCurve# ping docservr
10.28.229.219 is alive, time = 1 ms
ProCurve# traceroute docservr
traceroute to 10.28.229.219
1 hop min, 30 hops max, 5 sec. timeout, 3 probes
1 10.28.192.2
2 10.28.229.219
Figure C-22. Example of Ping and Traceroute Execution for the Network in Figure 20 on Page 53
ProCurve# ping docservr.pubs.outdoors.com
10.28.229.219 is alive, time = 1 ms
ProCurve# traceroute docservr.pubs.outdoors.com
traceroute to 10.28.229.219
1 10.28.192.2
2 10.28.229.219
Figure C-23. Example of Ping and Traceroute Execution When Only the DNS Server IP Address Is Configured
C-54
With the above already configured, the following commands enable ping and
traceroute with the host name docserver to reach the document server at
10.28.229.219.
1 ms
0 ms
Traceroute Target
As mentioned under "Basic Operation" on page C-49, if the DNS entry config-
ured in the switch includes only the DNS server's IP address, you must use the
target host's fully qualified domain name with ping and traceroute. For
example, using the document server in figure20 as a target:
1 hop min, 30 hops max, 5 sec. timeout, 3 probes
1 ms
0 ms
First-Hop Router ("B")
0 ms 0 ms
0 ms 0 ms
0 ms 0 ms
0 ms 0 ms
Target's Fully Qualified
Domain Name
