PoE Devices

The Power Over Ethernet (PoE) features described operate on the Series
5400zl and Series 3500yl switches. (The Series 6200yl switches do not offer
PoE.)
PoE on Series 5400zl Switches
The Series 5400zl switches are used as a Power Sourcing Equipment (PSE)
device providing PoE power to the Powered Devices (PDs) through the 24
Gig-T PoE module (J8702A), or the 20-port Gig-T plus 4 mini-GBIC PoE module
(J8705A). The switch must have at least one of the following power supplies
installed:
ProCurve J8712A Power Supply providing 273 watts of PoE power
■
■ ProCurve J8713A Power Supply providing 900 watts of PoE power
For information about the power supply specifications refer to the ProCurve
Switch zl Internal Power Supplies Installation Guide provided with your
power supply.
PoE on Series 3500yl Switches
There are two Series 3500yl switches that are used as PSE devices to provide
PoE power thru the RJ-45 ports:
Switch 3500yl-24G-PWR supplies up to 398 watts of PoE power
■
distributed across 24 RJ-45 ports.
Switch 3500yl-48G-PWR supplies up to 398 watts of PoE power
■
distributed across 48 RJ-45 ports.
The Series 3500yl switches have four dual-personality Gigabit uplink ports that
have either auto-sensing 10/100/1000Base-T RJ-45 ports or mini-GBIC connec-
tivity. The mini-GBIC ports do not support PoE.
