Configuration - ProCurve 6200yl Management And Configuration Manual

Port Traffic Controls
Guaranteed Minimum Bandwidth (GMB)
13-24
Either of the following commands configures ports A1 through A5 with
bandwidth settings:
ProCurve(config)#int a1-a5 bandwidth-min output 2 3 30 10
10 10 15 20
ProCurve(eth-A1-A5)#bandwidth-min output 2 3 30 10 10 10
15 20
Displaying the Current Guaranteed Minimum Bandwidth

Configuration

This command displays the per-port GMB configuration in the running-config
file.
Syntax: show bandwidth output [ port-list ]
Without [ port-list ], this command lists the GMB configuration
for all ports on the switch. With [ port-list ], this command lists
the GMB configuration for the specified ports. This command
operates the same way in any CLI context. If the command
lists Disabled for a port, there are no bandwidth minimums
configured for any queue on the port. (Refer to the description
of the no form of the bandwidth-min output command on page
13-21.)
For example, to display the GMB configuration resulting from either of the
above commands:
ProCurve(config)# show bandwidth output a1-a5
Outbound Guaranteed Minimum Bandwidth %
Port Q1 Q2
---- -- --
A1 2 3
A2 2 3
A3 2 3
A4 2 3
A5 2 3
Figure 13-6. Example of Listing the Guaranteed Minimum Bandwidth
Configuration
Q3 Q4 Q5 Q6
-- -- -- --
30 10 10 10
30 10 10 10
30 10 10 10
30 10 10 10
30 10 10 10
Q7 Q8
-- --
15 20
15 20
User-Configured
15 20
Minimum
15 20
Bandwidth
Settings
15 20
