SMART SCALER
TABLE OF CONTENTS
PAGES 2 - 3
PAGE 4
PAGE 5
PAGES 6
PAGES 7 - 9
PAGES 10 - 15
PAGE 16
PAGES 17 - 18
PAGES 19 - 27
PAGE 28
PAGE 29
(SMS100)
User's Manual
Safety Instructions
Supplied Equipment and General Information
Installing
Technical Description
Starting
LCD Menu & Control
Operating Mode
Technical Specifications
Remote Control RS-232
Troubleshooting and Optional Accessories
Warranty
ANALOG WAY
SMS100 - ED 07/01
TM
PAGE 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMS100 Smart Scaler and is the answer not in the manual?

Questions and answers

Related Manuals for Analog way SMS100 Smart Scaler

Summary of Contents for Analog way SMS100 Smart Scaler

  • Page 1 PAGES 10 - 15 LCD Menu & Control PAGE 16 Operating Mode PAGES 17 - 18 Technical Specifications PAGES 19 - 27 Remote Control RS-232 PAGE 28 Troubleshooting and Optional Accessories PAGE 29 Warranty ANALOG WAY SMS100 - ED 07/01 PAGE 1...
  • Page 2 OUVERTURES ET ORIFICES : Les appareils peuvent comporter des ouvertures (aération, fentes, etc...), veuillez ne jamais y introduire d’objets et ne jamais obstruer ses ouvertures. Si un liquide ou un objet pénètre à l’intérieur de l’appareil, débranchez l’appareil et faites le contrôler par un personnel qualifié avant de le remettre en service. ANALOG WAY PAGE 2 SMS100 - ED 07/01...
  • Page 3 ABERTURAS Y ORIFICIOS : Los aparatos pueden contener aberturas (aireación, ranuras, etc.). No introduzca allí ningún objeto ni obstruya nunca estas aberturas. Si un líquido o un objeto penetra al interior del aparato, desconéctelo y hágalo revisar por personal cualificado antes de ponerlo nuevamente en servicio. ANALOG WAY SMS100 - ED 07/01 PAGE 3...

  • Page 4: Supplied Equipment

    • The input source aspect ratio 4/3,16/9, Widescreen can be selected as well as the size of the SCREEN (4/3-16/9). • The Frame Conversion & Time base correction provides High End A/V Pro & Home Theater solutions. ANALOG WAY PAGE 4...
  • Page 5 - Be sure that no weight is added to the SMART SCALER™ in excess of 2 kg (4.4 lbs.). - The maximum ambient operating temperature must not exceed 40°C (105°F). - The rack and all mounted equipment in it must be reliably grounded to national and local electrical codes. ANALOG WAY SMS100 - ED 07/01 PAGE 5...

  • Page 6: Video Inputs

    RGB SYNC / R-Y, Y, B-Y : RGB/S or YUV (COMPONENT) video inputs on 3 or 4 BNC connectors. DISPLAY OUTPUT : DATA output (RGB HV or RGB.S) on 4 or 5 BNC connectors. ANALOG WAY PAGE 6 SMS100 - ED 07/01...
  • Page 7 (VCR, DVD, CAMERA…), but is also the lowest in picture quality. The video standard of this signal could be NTSC, PAL or SECAM. The signal is transmitted by a single coaxial cable, and is connected to the video equipment with a RCA or BNC connector. CONNECTION ANALOG WAY SMS100 - ED 07/01 PAGE 7...

  • Page 8: S.video Inputs

    COMPOSITE and S.VIDEO signals. The RGB.S connectors are usually BNC connectors for Broadcasting equipment, and SCART connector for DVD player and Satellite Receiver. CONNECTION ANALOG WAY PAGE 8 SMS100 - ED 07/01...
  • Page 9 If your display device accept only Composite Sync, connect the C.SYNC cable to the H BNC of the SMART SCALER™ and select COMP (Composite Sync.) in the LCD menu # 2-1 (Please see chapter 6). CONNECTION ANALOG WAY SMS100 - ED 07/01 PAGE 9...

  • Page 10: Control Button

    11 image process Gamma Sharpness Subtitle Coring Adapt black 12 Preset 4 control menu 1 languages English 2 panel locking all unlock all lock 3 black delay short long 4 version 5 default value ANALOG WAY PAGE 10 SMS100 - ED 07/01...
  • Page 11 • [AUTO] = Automatic recognition. • [NTSC] = NTSC detection only. • [PAL] = PAL detection only. • [SECAM] = SECAM detection only. • [Black & White] = Black and White detection only. ANALOG WAY SMS100 - ED 07/01 PAGE 11...
  • Page 12 • 1365 x 1024L (D-ILA at 50 Hz or 59.94 Hz- 4/3) NOTE: The output rate is 50 Hz for PAL & SECAM video inputs, or 59.94 Hz for NTSC video inputs. ANALOG WAY PAGE 12 SMS100 - ED 07/01...
  • Page 13 COMPUTER INPUT. The image settings and adjustments can be different and memorized for each video ² input separately. 3-1 [H POSITION] + ENTER Adjust the Horizontal position with + ENTER 3-2 [V POSITION] + ENTER Adjust the Vertical position with + ENTER ANALOG WAY SMS100 - ED 07/01 PAGE 13...
  • Page 14 3-12 [PRESET] + ENTER • [YES] = Erases all of the Image Settings (#3-1, #3-2, ... #3-11) and sets them back to the Factory Settings. • [NO] = Do not erase the Image Settings memorized. ANALOG WAY PAGE 14 SMS100 - ED 07/01...
  • Page 15 2-3 OUTPUT RATE = VIDEO IN RATE 2-4 TYPE OF SCREEN = 4/3 3-5 U / OVER SCAN = UNDERSCAN 3-6 ASPECT RATIO = 4/3 STANDARD 3-12 PRESET = YES 4-3 BLACK DELAY = SHORT ANALOG WAY SMS100 - ED 07/01 PAGE 15...

  • Page 16: Operating Mode

    NOTE : The image adjustments are only active for the selected video input. NOTE : To preset your image adjustment, select one video to display in output, then use the LCD menu # 3-12 (Preset). ANALOG WAY PAGE 16 SMS100 - ED 07/01...
  • Page 17 : • If computer input is selected : the output format is the same as the Computer input, Format • If a video input is selected : the output format is one of the format available in the LCD menu # 2-2. ANALOG WAY SMS100 - ED 07/01 PAGE 17...
  • Page 18 : 10% to 80% (without condensation) Dimensions : D 300 x W 440 x H 44mm / D 11.8" x W 17.3" x H 1.74" Weight : 3.4 kg / 7.48 lbs. ANALOG WAY PAGE 18 SMS100 - ED 07/01...
  • Page 19 TRANSMIT DATA (Tx) RECEIVE DATA (Rx) GROUND (Gnd) DB 9 female (Rear panel of the SMART SCALER™) • SPEED TRANSMISSION : 9600 Bauds, 8 Data bits, 1 Stop bit, No Parity bit. ANALOG WAY SMS100 - ED 07/01 PAGE 19...
  • Page 20 - COMMANDS (Read only : STATUS) : U, l, t, P, p, v, n, ?, K, L, R and X. ( PARAMETER ) < COMMAND > a character (Usually a letter) Without parameter : Reads back the current value ex : I ⇒ ICHAN1 ↵ ANALOG WAY PAGE 20 SMS100 - ED 07/01...

  • Page 21: Commands And Responses Table

    (13 = SMART SCALER™) 65535 "K" FIRMWARE VERSION READS K VERSION "L" FIRMWARE VERSION 65535 READS L VERSION "R" FIRMWARE VERSION 65535 READS R VERSION "X" FIRMWARE VERSION 65535 READS X VERSION ANALOG WAY SMS100 - ED 07/01 PAGE 21...

  • Page 22: Input Commands

    • w, x, y, z commands are used to select the video standard of the C.VIDEO 1, C.VIDEO 2, S.VIDEO 1 and S.VIDEO 2 input. DECIMAL VALUE SELECTION RESPONSE AUTOMATIC ISTD__0 NTSC (3.58 / 60Hz) ISTD__1 PAL (4.43 / 50Hz) ISTD__2 SECAM ISTD__3 BLACK & WHITE ISTD__4 ANALOG WAY PAGE 22 SMS100 - ED 07/01...
  • Page 23 OFMT12 SXGA (1280 x 1024) at 75Hz OFMT13 • u command is used to select the Output Frame Rate. DECIMAL VALUE SELECTION RESPONSE (OUTPUT RATE) INTERNAL RATE SSYNC0 VIDEO IN RATE SSYNC3 ANALOG WAY SMS100 - ED 07/01 PAGE 23...

  • Page 24: Image Commands

    • t command returns the Computer lines per Frame (CFD value). The following formula allows to calculate the computer input frame frequency in Hz. INPUT LINE FREQUENCY (Hz) = Input frame frequency in Hz. CFD VALUE ANALOG WAY PAGE 24 SMS100 - ED 07/01...
  • Page 25 VCHAN7 • n command is used to know the reference of the Output Frame Rate. (RESPONSE : SCSTA_). DECIMAL VALUE STATUS OF FRAME RATE RESPONSE INTERNAL RATE SCSTA0 VIDEO IN RATE SCSTA3 ANALOG WAY SMS100 - ED 07/01 PAGE 25...

  • Page 26: Miscellaneous Commands

    Reserved for manufacturer Reserved for manufacturer 0 = Screen 4/3 (action) 1 = Screen 16/9 (action) • ?, K, R, L, X, commands are the status of the device’s internal firmware (read only). ANALOG WAY PAGE 26 SMS100 - ED 07/01...

  • Page 27: Ascii / Hex / Dec Table

    9) REMOTE CONTROL RS-232 (continued) 9-2) HOST / SMART SCALER™ COMMUNICATION (continued) ASCII / HEX / DEC TABLE ASCII ASCII ASCII space " & ’ < > ANALOG WAY SMS100 - ED 07/01 PAGE 27...

  • Page 28: Troubleshooting

    REMOTE CABLE (DB 9 M/F) 3 m / 10ft 10110 REMOTE CABLE (DB 9 M/F) 5 m / 16 ft 10111 REMOTE CABLE (DB 9 M/F) 10 m / 33 ft 10112 ANALOG WAY PAGE 28 SMS100 - ED 07/01...

  • Page 29: Warranty

    WARRANTY Analog Way warrants the product against any defects in materials and workmanship for a period of three years from the date of purchase (back to the factory). In the event of any malfunction during the warranty period, Analog Way will, at its option, repair or replace the defective unit, including free material and labor.
