Analog way SMS100 Smart Scaler Operating Manual page 23

9) REMOTE CONTROL RS-232 (continued)
9-2) HOST / SMART SCALER™ COMMUNICATION (continued)
OUTPUT COMMANDS :
•
o command is used to select the Output Sync. type.
DECIMAL VALUE
• O command is used to select the output format.
Use the following table when the u command (Output Frame Rate) is set on Video In Rate (SSYNC3).
DECIMAL VALUE
Use the following table when the u command (Output Frame Rate) is set on Internal Rate (SSYNC0).
DECIMAL VALUE
•
u command is used to select the Output Frame Rate.
DECIMAL VALUE
0
1
SELECTION (OUTPUT FORMAT)
0 VGA (640 x 480) at 50Hz or 59.94 Hz
1 PLASMA 42" (852 x 480) at 50Hz or 59.94 Hz
2 SVGA (800 x 600) at 50Hz or 59.94 Hz
4 XGA (1024 x 768) at 50Hz or 59.94 Hz
5 PLASMA 50" (1280 x 768) at 50Hz or 59.94 Hz
6 SXGA (1280 x 1024) at 50Hz or 59.94 Hz
14 HDTV 720 P (1280 x 720) at 50Hz or 59.94 Hz
15 QUAD 960 (1280 x 960) at 50Hz or 59.94 Hz
16 D-ILA (1365 x 1024) at 50Hz or 59.94 Hz
SELECTION (OUTPUT FORMAT)
0 VGA (640 x 480) at 60Hz
1 PLASMA 42" (852 x 480) at 60Hz
2 SVGA (800 x 600) at 60Hz
3 MAC (640 x 480) at 66Hz
4 XGA (1024 x 768) at 60Hz
5 PLASMA 50" (1280 x 768) at 56Hz
6 SXGA (1280 x 1024) at 60Hz
7 VGA (640 x 480) at 75Hz
8 PLASMA 42" (852 x 480) at 72Hz
9 SVGA (800 x 600) at 75Hz
10 MAC 16" (832 x 624) at 75Hz
11 XGA (1024 x 768) at 75Hz
12 PLASMA 50" (1280 x 768) at 75Hz
13 SXGA (1280 x 1024) at 75Hz
0
3
SMS100 - ED 07/01
SELECTION
(OUTPUT SYNC TYPE)
SEPARATE H & V SYNC.
COMPOSITE SYNC.
SELECTION
(OUTPUT RATE)
INTERNAL RATE
VIDEO IN RATE
ANALOG WAY
RESPONSE
OSIG0
OSIG1
RESPONSE
OFMT0
OFMT1
OFMT2
OFMT4
OFMT5
OFMT6
OFMT14
OFMT15
OFMT16
RESPONSE
OFMT0
OFMT1
OFMT2
OFMT3
OFMT4
OFMT5
OFMT6
OFMT7
OFMT8
OFMT9
OFMT10
OFMT11
OFMT12
OFMT13
RESPONSE
SSYNC0
SSYNC3
PAGE 23
