Analog way SMS100 Smart Scaler Operating Manual page 13

6) LCD MENU & CONTROL (continued)
6-2) LCD MENUS (continued)
• If [OUTPUT RATE] = [INTERNAL RATE], the LCD window displays the following formats :
Select an output format with
• VGA 60 Hz (640 x 480 at 60 Hz)
• Plasma 42" 60 Hz (852 x 480 at 60 Hz)
• SVGA 60 Hz (800 x 600 at 60 Hz)
• MAC 66 Hz (640 x 480 at 66 Hz)
• XGA 60 Hz (1024 x 768 at 60 Hz)
• Plasma 50" 56 Hz (1280 x 768 at 60 Hz)
• SXGA 60 Hz (1280 x 1024 at 60 Hz)
• VGA 75 Hz (640 x 480 at 75 Hz)
• Plasma 42" 72 Hz (852 x 480 at 72 Hz)
• SVGA 75 Hz (800 x 600 at 75 Hz)
• MAC 16" 75Hz (832 x 624 at 75 Hz)
• XGA 75 Hz (1024 x 768 at 75 Hz)
• Plasma 50" 75Hz (1280 x 768 at 75 Hz)
• SXGA 75 Hz (1280 x 1024 at 75 Hz)
NOTE : For fixed pixel display device (DMD, LCD, PLASMA...), always select the output format corresponding
to the native resolution of the display device. This way, the display device will not have to scale the image
and the result will be better.
2-3 [OUTPUT RATE] + ENTER
Select an item with
• [INTERNAL RATE] = The output Frame Rate is 60 Hz or 75 Hz depending of the selected OUTPUT
• [VIDEO IN RATE] =
2-4 [TYPE OF SCREEN]
Select an item with
• [4/3] = if your image is displayed on a 4/3 screen.
• [16/9] = if your image is displayed on a 16/9 screen.
NOTE: The 16/9 type of screen mode does not support the NTSC 4/3 standard image if the selected Output
format is 1280 x 960L, 1280 x 1024L, 1365 x 1024L (D-ILA), XGA 75Hz or SXGA.
[IMAGE MENU] + ENTER
3
NOTE : This menu is available and active only on the selected video source displayed in output. This menu is not available
for the COMPUTER INPUT. The image settings and adjustments can be different and memorized for each video
² input separately.
3-1 [H POSITION] + ENTER
Adjust the Horizontal position with
3-2 [V POSITION] + ENTER
Adjust the Vertical position with
+ ENTER
+ ENTER
format (LCD menu # 2-2). A high level frame frequency gives a better visual
aspect when displaying static pictures.
The Output Frame Rate is identical to the Video Input Frame Rate : 50 Hz frame
rate if the video is PAL or SECAM and 59.94 Hz if the video is NTSC.
This function allows to improve the motion pictures.
+ ENTER
+ ENTER
+ ENTER
ANALOG WAY
SMS100 - ED 07/01 PAGE 13
