1) SUPPLIED EQUIPMENT

2) GENERAL INFORMATION

The SMART SCALER ™ combines the functions of a High Resolution Video Scaler with a video switcher. In
addition, a Computer or external input is provided for direct display of your Presentations or Internet
applications.
• The SMART SCALER™ is a state of the art improved SCALER / LINE MULTIPLIER which significantly
increases the Video image resolution and brightness. The very High Quality decoder includes an Advanced Comb
Filter, an anphasized "natural" color processing, a highly robust sync. detection and a new enhanced 3D auto-
adaptive de-interlacing scheme (for motion artifacts), with correction of the "film to video" transfer (3/2 pulldown
for NTSC). It provides you with a "cinema like" image.
• In addition, and according to your requirements, you can continuously adjust special image parameters like the
Sharpness for details emphasis, the Stepness Enhancer for subtitle readability improvements, the Coring processor
for removing High Frequency noise found in some "VCR" tapes without affecting the bandwidth, and the Gamma
Corrector, which optimizes your CRT, DLP, LCD's Luma response.
• The input source aspect ratio 4/3,16/9, Widescreen can be selected as well as the size of the SCREEN (4/3-16/9).
• The Frame Conversion & Time base correction provides High End A/V Pro & Home Theater solutions.
PAGE 4
SMART SCALER
• 1 SMART SCALER TM
• 1 Set of 19" Brackets
• 1 AC Power supply cord
• 1 VGA cable (HD15 Male / Male)
• 1 S.VIDEO (Y/C) cable
• 1 RCA Male /Male cable
• 1 RCA Female / BNC Male adapter
• 1 5xBNC to HD15 Female cable
• 1 User's Manual
ANALOG WAY
SMS100 - ED 07/01
TM
(SMS100)
