8) TECHNICAL SPECIFICATIONS
8-1) VIDEO INPUTS
• RGB.S (4 BNC CONNECTORS)
15.625 kHz / 50 Hz .... 15.735 kHz / 60 Hz (625L .....525L)
Levels
Impedance
• COMPONENT (YUV) - R-Y / Y / B-Y (3 BNC CONNECTORS)
15.625 kHz / 50 Hz .... 15.735 kHz / 60 Hz (625L .....525L)
Levels
Impedance
• S.VIDEO (Y/C) (4 PIN MINI DIN CONNECTOR & 2 BNC CONNECTORS)
PAL / SECAM 15.625 kHz / 50 Hz (625L)
NTSC 3.58 MHz / 4.43 MHz 15.735 kHz / 60 Hz (525L)
Levels
Impedance
• COMPOSITE VIDEO (BNC CONNECTOR)
PAL / SECAM 15.625 kHz / 50 Hz (625L)
NTSC 3.58MHz / 4.43 MHz 15.735 kHz / 60 Hz (525L)
Level
Impedance
8-2) COMPUTER INPUT (15 PINS HD F CONNECTORS)
Hardware compatibility
NOTE : The COMPUTER input is passed directly through to the DISPLAYED OUTPUT connector. You can also
connect a Computer source (PC, MAC, WORKSTATION) or a High Definition video source (progressive
DVD player, HDTV) to the COMPUTER INPUT.
8-3) DISPLAY OUTPUT (4/5 BNC CONNECTORS)
Levels
Impedance
Format
: R, G, B = 3 x 0.7 Vp/p
: SYNC. = 0.3 Vp/p or TTL
: RGB = 75 Ohms
SYNC. = 75 Ohms or Hi-Z
: Y = 0.3 Vp/p (Sync.) + 0.7 Vp/p (Luma)
: R-Y = 0.7 Vp/p / B-Y = 0.7 Vp/p
: Y, R-Y B-Y = 75 Ohms
,
: Y = 1 Vp/p (0.7 Vp/p Luma + 0.3 Vp/p Sync.)
: C = 0.3 Vp/p (Chroma Burst)
: 75 Ohms
: 1 Vp/p (0.7 Vp/p Luma + 0.3 Vp/p Sync.)
: 75 Ohms
: Line frequency : from 15 kHz to 100 kHz
: Frame frequency : from 24 Hz to 120 Hz
: R, G, B = 0.7 Vp/p
: Sync. : H & V separated = TTL
: COMP. Sync. = TTL
: R, G, B, H & V and COMP. Sync. = 75 Ohms
: • If computer input is selected : the output format is the same as the Computer input,
• If a video input is selected : the output format is one of the format available in the
LCD menu # 2-2.
