6) LCD MENU & CONTROL (continued)
6-2) LCD MENUS (continued)
3-3 [H SIZE] + ENTER
Adjust the Horizontal size with
3-4 [V SIZE] + ENTER
Adjust the Vertical size with
3-5 [U / OVER SCAN] + ENTER
Select Underscan or Overscan with
• [UNDERSCAN] = Output image is full screen.
• [OVERSCAN] = Output image is 10% bigger than in Underscan mode.
[ASPECT RATIO] + ENTER
3-6
Select an Aspect Ratio with
• [4/3 standard] = 4/3 input Aspect Ratio.
• [letterbox] = 16/9 Letterbox Aspect Ratio.
• [WS anamorphic] = Widescreen anamorphic (to be used only if your DVD player is set in 16/9)
[BRIGHTNESS] + ENTER
3-7
Adjust the Brightness with
[CONTRAST] + ENTER
3-8
Adjust the Contrast with
[COLOR] + ENTER
3-9
Adjust the Color with
3-10 [HUE] + ENTER
Adjust the Tint of the picture (NTSC only) with
3-11 [IMAGE PROCESS] + ENTER
Select a function and adjust with
• GAMMA :
• SHARPNESS : Increase the details of the image.
• SUBTITLE : Increase the readability of subtitles.
• CORING :Reduce the noise of VCR tape.
• ADAPTIVE BLACK : Automatic black level correction.
3-12 [PRESET] + ENTER
• [YES] = Erases all of the Image Settings (#3-1, #3-2, ... #3-11) and sets them back to the Factory Settings.
• [NO] = Do not erase the Image Settings memorized.
PAGE 14
+ ENTER
+ ENTER
+ ENTER
+ ENTER
+ ENTER
+ ENTER
Gives greater depth to darker portions of the image for more exciting theater experience
or brightens dark portions for the image for more enhanced presentations.
ANALOG WAY
SMS100 - ED 07/01
+ ENTER
+ ENTER
+ ENTER, and valid with ENTER
