9) REMOTE CONTROL RS-232 (continued)
9-2) HOST / SMART SCALER™ COMMUNICATION (continued)
•
ERROR RESPONSES :
When the SMART SCALER™ receives from the host an invalid command or value, it returns an error response:
E10 ↵
Invalid command (See "COMMAND" column).
E13 ↵
Invalid value (See "VALUE" column).
•
COMMANDS DESCRIPTION
Values sent or received are in decimal. Depending on the command letter, the value can be used as a linear control (ex :
255W to set the horizontal size to the maximum) or as a set of bits (ex : P command with multiple controls). In this case,
the value must be converted in binary base to understand every bit action.
EXAMPLE Host receives message CSTA3 (P command)
Decimal value 3 = Binary value 011
3 = (4 x 0) + (2 x 1) + (1 x 1)
bit 0 = 1 means Sync. detected.
bit 1 = 1 means Comp. Sync. detected.
bit 2 = 0 means non interlaced format detected.

INPUT COMMANDS :

• I command is used to select an input.
• r command is used to select the video type of the RGB/YUV input.
• w, x, y, z commands are used to select the video standard of the C.VIDEO 1, C.VIDEO 2, S.VIDEO 1
and S.VIDEO 2 input.
PAGE 22
DECIMAL VALUE
1
3
4
5
6
7
DECIMAL VALUE
0
1
2
3
DECIMAL VALUE
0 AUTOMATIC
1 NTSC (3.58 / 60Hz)
2 PAL (4.43 / 50Hz)
3 SECAM
4 BLACK & WHITE
ANALOG WAY
SMS100 - ED 07/01
INPUT # SELECTION
COMPUTER
C.VIDEO 1
C.VIDEO 2
S.VIDEO 1
S.VIDEO 2
RGB / YUV
SELECTION
YUV
RGB/S (TTL)
RGsB (SOG)
RGB/S (75Ω)
SELECTION
RESPONSE
ICHAN1
ICHAN3
ICHAN4
ICHAN5
ICHAN6
ICHAN7
RESPONSE
IRGB0
IRGB1
IRGB2
IRGB3
RESPONSE
ISTD__0
ISTD__1
ISTD__2
ISTD__3
ISTD__4
