9) REMOTE CONTROL RS-232 (continued)
9-2) HOST / SMART SCALER™ COMMUNICATION (continued)

MISCELLANEOUS COMMANDS

• Y command is used to control different menus like the FRONT PANEL LOCK, the FREEZE...
(RESPONSE : CMD----).
Bit 15 Bit 14 Bit 13 Bit 12
(32768) (16384) (8192) (4096)
Reserved for manufacturer
Reserved for manufacturer
Reserved for manufacturer
0 = Screen 4/3 (action)
1 = Screen 16/9 (action)
• ?, K, R, L, X, commands are the status of the device's internal firmware (read only).
PAGE 26
Bit 11 Bit 10 Bit 9 Bit 8
(2048) (1024) (512) (256)
0 = Underscan image (action)
1 = Overscan image (action)
Reserved for manufacturer
Duration of the Black Delay
0 = Short time (action)
1 = Long time (action)
Reserved for manufacturer
ANALOG WAY
SMS100 - ED 07/01
Bit 7 Bit 6 Bit 5 Bit 4
(128) (64) (32) (16)
1 = Image Preset (action)
Please see LCD Menu 3-12
00 = Unlock (action)
01 = All lock (action)
1 = Freeze (action)
Bit 3 Bit 2 Bit 1 Bit 0
(8) (4) (2) (1)
Reserved
Reserved
0 = Adaptive Black OFF
1 = Adaptive Black ON
1 = Default value (action)
