9) REMOTE CONTROL RS-232 (continued)
9-2) HOST / SMART SCALER™ COMMUNICATION (continued)
•

COMMANDS AND RESPONSES TABLE

The following table resumes commands which are recognized as valid and the responses that will be returned to
the host (on the RS-232 port).
COMMAND RESPONSE
TO
ASCII
HOST
INPUT COMMANDS
I ICHAN
r IRGB
w ISTDC1
x ISTDC2
y ISTDS1
z ISTDS2
OUTPUT COMMANDS
O OFMT
o OSIG
u SSYNC
IMAGE COMMANDS (VIDEO ONLY)
H HPOS
V VPOS
W HSIZ
S VSIZ
B BRGT
C CONTR
s COLOR
T HUE
b IASP
j GAMMA
A SHARP
Q SUBTT
N NOISE
STATUS COMMANDS (READ ONLY)
U UNIT
l CLD
t CFD
P CSTA
p VSTA
v VCHAN
n SCSTA
MISCELLANEOUS COMMANDS
Y CMD
? DEV
K K_
L L_
R R_
X V_
COMMAND
DESCRIPTION
SELECTED INPUT
VIDEO TYPE OF RGB/YUV
INPUT
INPUT STANDARD C.VIDEO 1
INPUT STANDARD C.VIDEO 2
INPUT STANDARD S.VIDEO 1
INPUT STANDARD S.VIDEO 2
OUTPUT FORMAT
OUTPUT SYNC. TYPE
OUTPUT FRAME RATE
HORIZONTAL POSITION
VERTICAL POSITION
HORIZONTAL SIZE
VERTICAL SIZE
BRIGHTNESS ADJUSTMENT
CONTRAST ADJUSTMENT
COLOR SATURATION
HUE ADJUSTMENT (NTSC ONLY)
ASPECT RATIO
GAMMA ADJUSTMENT
SHARPNESS ADJUSTMENT
SUBTITLES ENHANCEMENT
NOISE REDUCTION
MEASURES UNITY IN kHz
DURATION OF A COMPUTER
LINE
NUMBER OF LINE PER FIELD
OF COMPUTER
COMPUTER STATUS
VIDEO STATUS
INPUT NUMBER OF THE VIDEO
WHICH STATUS IS GIVEN
SCALER SYNCHRONIZATION
MISCELLANEOUS CONTROL
DEVICE TYPE
"K" FIRMWARE VERSION
"L" FIRMWARE VERSION
"R" FIRMWARE VERSION
"X" FIRMWARE VERSION
VALUE
MIN MAX COMMAND RESPONSE
1 7
0 3
0 4
0 4
0 4
0 4
0 16
0 1
0 3
255
0 20H
0 255
0 255
0 255 157S
0 255
0 255
0 255
0 255
0 2
63
0
0 63
0 63
0 63
65535
0
0 65535
0 65535
0 31
0 16
7
0
3
0
0 32768 128Y
65535
0
65535
0
0 65535
0 65535
0 65535
ANALOG WAY
SMS100 - ED 07/01
EXAMPLE
ACTION EXPLANATION
5I ICHAN5 SELECTS S.VIDEO 1 INPUT
r IRGB1 READS VIDEO TYPE OF THE
RGB/YUV INPUT
w ISTDC10 READS THE VIDEO STANDARD
DETECTION
x ISTDC21 READS THE VIDEO STANDARD
DETECTION
y ISTDS14 READS THE VIDEO STANDARD
DETECTION
z ISTDS21 READS THE VIDEO STANDARD
DETECTION
O OFMT2 READS THE OUTPUT FORMAT
1o OSIG1 SETS THE OUTPUT SYNC.
TO COMP. SYNC.
3u SSYNC3 SETS THE OUTPUT FRAME
RATE TO VIDEO IN RATE
HPOS20 SETS H. POSITION TO 20
V VPOS73 READS V POSITION
W HSIZ128 READS H WIDTH
VSIZ157 SETS V SIZE TO 157
B BRGT15 READS BRIGHTNESS LEVEL
C CONTR50 READS CONTRAST LEVEL
s COLOR125 READS COLOR SATURATION
LEVEL
T HUE120 READS HUE LEVEL
2b IASP2 SETS ASPECT RATIO TO 16/9
j GAMMA0 READS GAMMA LEVEL
A SHARP20 READS SHARPNESS LEVEL
Q SUBTT55 READS SUBTITLE LEVEL
N NOISE10 READS NOISE REDUCTION
LEVEL
U UNIT---- READS UNITY OF MEASURE
l CLD---- READS LINE FREQUENCY OF
SELECTED COMPUTER
t CFD---- READS LINE PER FIELD OF
SELECTED COMPUTER
P CSTA---- READS COMPUTER STATUS
p VSTA13 READS THE VIDEO STATUS
v VCHAN7 VIDEO STATUS IS FOR
RGB/YUV INPUT
n SCSTA3 VIDEO IN RATE
CMD128 FREEZE ACTION
? DEV13 READS DEVICE TYPE
(13 = SMART SCALER™)
K K_ READS K VERSION
L L_ READS L VERSION
R R_ READS R VERSION
X V_ READS X VERSION
PAGE 21
