Specifications; Ecl-Nvr16M Series - Eclipse Security ECL-NVR16 User Manual

1.3.7 ECL-NVR16M
Parameter

Specifications

ECL-NVR16M
Max support 16-ch standard definition with the transmission rate of 2Mbps for each
channel;
8-channel 720P, with the transmission rate of 4Mbps for each channel;
System
4-channel 1080P, with the transmission rate of 8Mbps for each channel;
Resources
Support 20 online users at the same time,
The image delay time of each channel is under 500ms.
Operation
Embedded Linux real-time operation system
System
Operation
WEB/Local GUI
Interface
Video
H.264/MPEG4
Compression
Encode
For H.264, it max supports 16-channel D1, 8-channel 720, 4-channel 1080P.
Capacity
Audio
G.711a
Compression
1-channel VGA analog video output.
Video Output
4/8/16-ch network compression video input
Video Input
1-ch HDMI output.
HDMI
1-ch bidirectional audio input
Audio Input
1-ch bidirectional talk output.
Audio Output
11
