ECL-NVR16M Series

2.1.4
The front panel is shown as in Figure 2-4.
Please refer to the following sheet for front panel button information.
Name
Power button
Number button
Shift
Fast play
Slow play
Play/Pause
Reverse/Pause
Play previous
Icon
Power button, press this button for three seconds to boot
up or shut down NVR.
Number 0-9 and
etc
Various fast speeds and normal playback.
Multiple slow play speeds or normal playback.
In playback mode, playback the previous video
Figure 2-4
Function
Input Arabic number
Switch channel
In textbox, click this button to switch between
numeral, English (Small/Capitalized), donation and
etc.
Enable or disable tour.
In backward playback or pause mode, click this
button to go normal playback.
In normal playback click this button to pause
playback
In pause mode, click this button to resume playback.
In normal playback or pause mode, click this button to
reverse
playback
27
