main stream. A stands for
4) When you switch from Monitor to Search or Configuration, system pops a dialogue box asking
you leave current interface or not. See Figure 7-16.Click the OK button, system will close current
monitor window. For example, you click the Config button when you are monitoring, system pos
up a following dialogue. Click the OK button, system closes current monitor interface and open
the configuration interface. The monitor interface appears automatically after you close
configuration interface. When you switch from Search to the Configuration interface, system
also pops up the same dialogue box for your confirmation. Click OK button, you can see system
close playback interface and open the configuration interface. Please note, system will not open
the playback interface again after you close the configuration interface.
5) If you login via the WAN mode, system does not support alarm activation to open the video
function in the Alarm setup interface.
Important
For multiple-channel monitor mode, system adopts extra stream to monitor by default. You
can not modify manually. All channels are trying to synchronize. Please note the
synchronization effect still depends on your network environments.
For bandwidth consideration, system can not support monitor and playback at the same time.
System auto closes monitor or playback interface when you are searching setup in the
configuration interface. It is to enhance search speed.

7.4 Configuration

System Information

7.4.1

7.4.1.1 Version Information

Here you can view device hardware feature and software version information. See Figure 7-17.
Figure 7-16
149
