Alarm Connection - Eclipse Security ECL-NVR16 User Manual

Port Name
A RS485
（RS-485）
communication
port
B
CTRL 12V
+12V
Network port
eSATA eSATA port
USB port.
RS232(RS-422) RS232 debug
COM.
HDMI High Definition
Media
Interface
VGA VGA video
output port

2.3 Alarm Connection

Please refer to the steps listed below.
Connect the alarm input device to the alarm input port.
Connect the alarm output device to the alarm output port. The NO and NC alarm output
device can connect to the NO/C/NC port. For the NO alarm device, please connect to the
NO/C ports. For the NC alarm device, please connect to the NC/C ports. Please note the
NO/C ports are for NO alarm device only.
Open Web, and go to the Alarm setup interface to set the alarm input and output. The alarm
01 is corresponding to the first channel of the device I/O port and so on. Please set the
NO/NC type according to the high/low level the alarm input device generated when an alarm
occurred
Connection Function
/ /
/ /
/
/
RS485_A port. It is the cable A. You can
connect to the control devices such as speed
dome PTZ.
RS485_B.It is the cable B. You can connect
to the control devices such as speed dome
PTZ.
Controller 12V power output. It is to control
the on-off alarm relay output. It can be used
to control the device alarm output. At the
same time, it can also be used as the power
input source of some devices such as the
alarm detector.
+12V power output port. It can provide the
power to some peripheral devices such as
the camera or the alarm device. Please note
the supplying power shall be below 1A.
Two 10M/100M/1000M self-adaptive
Ethernet ports. Connect to the network cable.
External SATA port. It can connect to the
device of the SATA port. Please jump the
HDD when there is peripheral connected
HDD.
Connect to USB mouse.
It is for general COM debug to configure IP
address or transfer transparent COM data.
High definition audio and video signal output
port. It transmits uncompressed high
definition video and multiple-channel data to
the HDMI port of the display device.
VGA video output port. Output analog video
signal. It can connect to the monitor to view
analog video.
