7.4.4.2 Auto register

The auto register interface is shown as in Figure 7-58.
You can set the server IP and port if you want to use the auto register function. After the device
registered to the server, you can access the device after the client-end connected to the server.

7.4.4.3 Mobile Config

The mobile setup interface is shown as in Figure 7-59.
Here you can activate or disconnect device 3G connection such as telephone or mobile phone, or
the alarm activated message No.
It is to switch video left and right limit.
This function is disabled by default.
It is to switch video up and bottom limit.
This function is disabled by default.
Please note the video resolution shall be 720P or lower when it
is to flip 90°.
Enable this function to check the video has been tampered with
or not.
Figure 7-58 Auto register
