1-2. Specifications

<4CH>
Image Input/Output : NTSC / PAL
Recording Speed :
NTSC - 1~123fps(based on 360X240)
PAL - 1~103fps(based on 360X288)
Compression Method : MPEG4 Technology
Recording Time : 48~17,780 hours (160G)
Power : DC12V, 4.5A (DC adapter)
Power Consumption : 34W
External Terminal : Video Input - BNC 4CH
Temperature : 5~40℃(30~110 F)
Humidity : 20%~80%(Non-condensing)
Size : 277 (W) × 315 (D) × 80 (H) mm
Weight : Lighter than 4.5Kg(Supplements and Packing Materials Excluded)
Supplements : Adapter 1
Power Cable 1
Program CD 1
Remote Controller 1
Battery 2
Video Output - BNC 1CH, S-Video 1CH, VGA 1CH(optional)
Spot Out- BNC 1CH
Loop Out - Loop Through 4CH
Audio Input - RCA 4CH
Audio Output - RCA 1CH
Sensor Input - Terminal Block 4CH (Contact, TTL)
Sensor Output - Terminal Block 4CH (Dry Contact)
LAN Communication - RJ45 Port
Serial Communication - DSUB9(RS-232C)
Terminal Block(RS485)
USB 1.1 Type A
6
CH 1 Product Introduction
