For the LAN mode, after you logged in, you can see the main window. See Figure 7-4.
①
There are six sections:
Section 1: Monitor channel menu tree
Section 2: System menu
Section 3: PTZ control
Section 4: Video setup and other setup
Section 5: Preview window
Section 6: Monitor window switch

7.2.1 Monitor Channel Menu Tree

The monitor channel menu tree is shown as in Figure 7-5.
Please note the following figure is for reference only. For 32-channel series product, there are 32
channels.
⑥
Figure 7-4 Main Interface
②
⑤
③
④
