HD Series Digital Video Recorder USER’S MANUAL...
Page 2
WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...
Page 3
IMPORTANT SAFEGUARDS 1. Read Instructions 13. Damage requiring Service Unplug this equipment from the wall outlet and refer servicing to All the safety and operating instructions should be read before the qualified service personnel under the following conditions: appliance is operated. A.
1. SAFETY CAUTIONS ※ Follow these instructions to keep the user safe and prevent property damage. Read them carefully before the use of the product. The responsibility falls on the user to install and use the product properly. 1.2 Installation-related 1.1 Power Source-related ①...
1.3 Cleaning and Usage-related ⑥ When cleaning the product, unplug the power ① Un p lu g the p o wer p l ug du rin g li ghtn in g , cord and gently wipe using a soft cloth. Do not thunderstorm or when not in use for long periods directly spray water on the product or do not use of time.
2. OUTLINE 2.1 Functions This DVR provide superior video image quality on Live view and Playback. • Pentaplex Operation Performance (Live, Recording, Playback, Backup, Network) • Up to maximum 16 channel composite input ports depending on model. • Various Recording mode. (Manual / Schedule / Event) •...
2.2 System Organization CAMERA HDMI/VGA KEYBOARD MONITOR CONTROLLER Video CAMERA Network input Video out Audio Audio Input SPOT MONITOR Alarm Sensors Audio Input Output SIREN SENSOR SPEAKER...
Page 11
3. DVR ORGANIZATION 3.1 Front Panel Description NOTE: Turn on the DVR after connecting the power cord, camera input and monitor completely Menu Power LED Number(1~0) Playback 2 x USB IR receiver...
Page 12
※ Front Button The front panel of DVR is similar as normal VCR or Multiplexer and the functions are also similar . Front buttons have various functions and are used for DVR initial setting and others. Please refer to the below explanation. NUMBER buttons (1 ~ 0) Displayed selected camera number to full screen.
Page 13
PTZ button Enter PTZ mode. SMART button Start smart search function. REPLAY button Start playback function. Direction Buttons (▲, ▼, ◀, ▶ ) This buttons are used when move to other menu or change the position of the CAMEO screen. In PTZ mode, it is used PAN/TILT function.
Page 14
3.2 Rear Panel HD-SDI camera DC adapter socket Network HDMI Output VGA Output input RS-485, 1 Alarm out, 4 Sensor Input, 4 Audio in 1 Out...
3.3 Front Panel Description NOTE: Turn on the DVR after connecting the power cord, camera input and monitor completely <Front DOOR CLOSE > POWER/HDD/NETWORK LED Remote control IR sensor Power REMOVABLE HDD RACK Menu CD_RW,DVD_RW Number Playback (1~0) Direction Jog / Shuttle USB2.0 port <Front DOOR OPEN >...
3.5 Remote Controller NUMBER MUTE OSD ON/OFF UP Direction Key LEFT Direction Key RIGHT Direction Key DOWN Direction Key ENTER MENU BACKUP SETUP STATUS DISPLAY FREEZE SQEUENCE ZOOM PANIC RECORDING PLAYBACK CONTROL ALARM SETUP SPOT SETUP ※ How to set ID ①...
4. LIVE 4.1 Live Screen Execution Information Message Camera Name Record Status Icon Live Screen PTZ Control Information Screen Screen Expand/Reduction Backup Progress Window Status(%) Current Date and Current Channel Current Event Information Time Information Icon Icon Sequence Icon - Record Icon (Red) - Video-loss Icon When record in live screen.
4.1.1 Top Menu In live screen, if ▲ button of the remote controller or front panel is pressed, or if the mouse cursor is placed over the end of the top area, the top menu is appeared. 4.1.2 Bottom Menu In Live screen, if ▼...
4.1.3 CAMEO Menu In live screen, if the ENTER button of the remote controller or front panel is pressed, a blue square cursor will be appeared. If the ENTER button is pressed again, the CAMERA menu will be appeared. ▪ CAMEO CHANGE : The live camera can be changed to the selected channel. If the camera number is selected at the pop-up menu shown below, the camera is changed to the selected channel.
Page 21
▪ PTZ : PTZ Camera should be installed otherwise the PTZ menu is not activated. The following picture will be appeared when select PTZ menu. ※ Using Mouse : On the above menu, when click the right button of mouse, the control screen for Menu, Zoom, Focus and Iris will be appeared.
Page 22
- SPEED SETUP : Set the PTZ camera speed. ( 1 to 8) NOTE: If the mouse is used to move the PTZ camera, the movement speed depends on the position of the mouse. As the mouse pointer moves away from the center, speed becomes faster. - PRESET SETUP : Set the preset position.
5. SETUP In this category, there are SYSTEM, NETWORK, DEVICE, RECORD and EVENT. On the Top menu, select the [SETUP] menu icon. After select the icon, the following LOGIN window will be appeared. Enter the password by the key buttons and press the OK button.
5.1.1 GENERAL [SYSTEM] ▪ LANGUAGE : Select the language. ▪ LANGUAGE : Select the language. (English, Germany, French, Spanish, Japanese, Chinese, Italian, Russian, Dutch and Korean) ▪ KEY TONE : Turn on/off the buzzer sound of key. ▪ UNIT ADDRESS : Set the DVR ID. This ID can be used when use multi DVR in same place by one remote controller.
Page 25
5.1.1 GENERAL [DATE / TIME] ▪ DATE FROMAT : Select the data format. (YY/MM/DD) / (MM/DD/YY) / (DD/MM/YY) ▪ TIMEZONE : Select the timezone and DST. The city which don’t use DST is set to [OFF] automatically. ▪ DATE DISPLAY : Display date on live screen or not. ▪...
5.1.2 ALARM OUT ▪ SIGNAL : Select on/off to use alarm by channel. ▪ ALARM SET TEST : Check the alarm connection whether it works properly or not. Press the [SET] button then alarm device will be operated. ▪ ALARM CLEAR TEST : Press the [CLEAR] button then alarm device will not be operated. ▪...
Page 27
[CHECK / USB] ▪ RECORD START TIME : Display the earliest recorded data information. ▪ RECORD START TIME : Display the earliest recorded data information. ▪ RECORD END TIME : Display the latest recorded data information. ▪ DISK CHECK : Check the data from the earliest recorded to the latest recorded. ▪...
5.1.4 MONITOR ▪ HDMI : Select the resolution for connected monitor. ▪ FILTER : ▪ BORDER COLOR : Change the border color. ▪ ALPHA BLENDING : Set the transparency of menu. (Set 1 to 20 and 20 is closer to the more transparent.) ▪...
5.1.5 ACCOUNT ※ Add / delete any user and give permission freely. ※ When add new user, have to input new password. When delete user, confirm again. NOTE: ( Default ADMIN password is 1), Initial user name can be modified but can not delete. CAUTION: Default Admin account must not be deleted before add new user.
5.1.6 CONFIG ▪ SLOT : Select the slot to load or save on DVR memory. ※ DEFAULT : Change factory default setting. ▪ DATE : Display the latest saved date. ▪ LOAD : Load the saved data. ▪ SAVE : Save the set data. ▪...
5.2 DEVICE SETUP In this category, there are Camera, PTZ, Spot, Sequence and Private Zone setting. Select the [DEVICE] Menu. 5.2.1 CAMERA ▪ CAMERA LABEL : Select the camera label of live screen. (ALL / NUMBER / NAME / OFF) ▪...
If select the camera name, the virtual keyboard will be appeared. Max camera name should be less than 11 character. [Virtual Keyboard] 5.2.2 PTZ [PTZ] ▪ PORT : Select the Baud Rate for using PTZ camera. ▪ ADDRESS : Select the ID for using PTZ camera. ▪...
5.2.3 SPOT CAMERA : Select the camera for display on spot monitor. DEFAULT : Select the camera for display on spot monitor when sequence is off. SEQUENCE : Select On/Off for sequence screen. DWELL : Select the interval time to move next channel. The max value is 256 sec. POPUP : Select On/Off for pop-up screen when event is occurred.
5.2.4 SEQUENCE PAGE DWELL TIME : Select the dwell time to move next channel. CAMEO DWELL TIME : Select the dwell time for CAMEO sequence. NOTE: CAMEO sequence means selected camera is rotated in select cameo of division screen. NOTE: CAMEO sequence means selected camera is rotated in select cameo of division screen. Camera image which is shown on the other CAMEO of division screen is not included in CAMEO sequence.
5.2.5 PRIVATE ZONE ▪ ZONE ENABLE : Select On/Off to use. (LIVE mode/ SEARCH mode) ▪ ZONE COLOR : Select the color to hide. ▪ ZONE : Select the zone to hide. (When select the ZONE button, the camera image will be appeared. (When select the ZONE button, the camera image will be appeared.
5.3 EVENT SETUP In this menu, there are Motion, Alarm in, Video Loss, System and Display setup. Select the [EVENT] menu. 5.3.1 MOTION [INPUT] ▪ ACTIVE : Select On/Off to activate motion. ▪ LEVEL : Select the sensitive for motion trigger. (Select 1 to 5 level) ▪...
Page 38
▪ AREA SETUP In the Area setup, the Red square is shown at the top left side of the screen. If select the OK button, the dot color will be changed to Green. A motion area can be selected by the direction buttons. NOTE : When the status is Red square, can move any direction to select.
Page 39
[ACTION] ▪ RECORD : Select the channel for record. ▪ ALARM : Select On/Off for alarm. ▪ BUZZER : Select On/Off for buzzer. ▪ PRESET : Set the preset number. ▪ PRESET : Set the preset number. (When motion is triggered, the PTZ camera move to the set preset number position) ▪...
5.3.2 ALARM IN TIP: If select the ACTIVE+ / TYPE+ menu, can change all setting at once. [INPUT] ▪ ACTIVE : Select On/Off to activate alarm. ▪ NAME : Type any name. ▪ TYPE : Select the alarm type. (NO : Normal Open / NC : Normal Close) [ACTION] ▪...
5.3.3 VIDEO LOSS TIP: If select the ACTIVE+ menu, can change all setting at once. [INPUT] ▪ ACTIVE : Select On/Off to activate. [ACTION] ▪ RECORD : Select On/Off for record. ▪ ALARM : Select On/Off for alarm. ▪ BUZZER : Select On/Off for buzzer. ▪...
5.3.4 SYSTEM [WARNING] ▪ CHECK INTERVAL : Select the check interval. (Select 1 hour to 24 hour) ▪ DISK WARNING : Select how to give a warning if disk error. (OFF, POPUP, POPUP + BUZZER) ▪ THRESHOLD : Critical value for Warning ▪...
[E-MAIL] – Select option On/Off for e-mail notification. ▪ POWER / MENU / LOGIN FAIL / DISK FULL / LOG IN / SMART 5.3.5 DISPLAY ▪ DISPLAY : Select display time by second. (Select 0 to 100) ▪ EVENT MESSAGE : Select On/Off to display event message. ▪...
5.4 RECORD SETUP Select the [RECORD] menu. In this menu, there are Setup, Record, Pre/Post, Audio, Panic Setup 5.4.1 SETUP & RECORD ▪ SETUP MODE : Select the record schedule. (CONTINUOUS / SCHEDULE) [CONTINUOUS] ▪ DAY TIME : Select the day time. (The night time is changed automatically according to the day time zone) ▪...
Page 45
[SCHEDULE] ▪ Set 3 different recording setup by day and time. (SET1, SET2, SET3) This is related with [RECORD] menu so [CUSTOM] mode should be matched with [RECORD] menu. TIP : For SET1, SET2, SET3 recording, change the setting [SETUP MODE] to [CONTINUOUS] and enter to the [RECORD] menu then change the setting.
5.4.2 EVENT PRE / POST ▪ PRE RECORD : Sets Pre-event recording time ( Max 60 second ) ▪ POST RECORD : Sets Post-event recording time ( Max 100 second ) 5.4.3 AUDIO ▪ RECORD : Select On/Off for audio recording by channel. TIP: If select the RECORD+ menu, can change all setting at once.
5.4.4 PANIC ▪ FPS : Select the recording frame by each channel. ▪ Quality : Select the resolution by each channel. ▪ AUDIO : Select On/Off for audio recording by each channel. ▪ AUDIO : Select On/Off for audio recording by each channel.
5.5 NETWORK SETUP In this menu, there are Network, Serial, DDNS, E-mail setup. Select the [NETWORK] menu. 5.5.1 LAN [SERVER] ▪ DHCP : Select On/Off for dynamic IP. If Dynamic IP is OFF, DVR get IP address from router automatically. ▪...
Page 49
[SERVER2] ▪ DHCP : Select On/Off for dynamic IP. ▪ IP ADDRESS : Type IP address. (Available when DYNAMIC IP is OFF) ▪ NETMASK : Type Subnet mask. (Available when DYNAMIC IP is OFF) [CLIENT] ▪ CLIENT ACCESS : Select client access options. ( ALL / RANGE ) ▪...
5.5.2 SERIAL [RS-232 INPUT SETUP] ▪ SERIAL TYPE : Select external device. ▪ MODEL : Select the protocol to use. ▪ PORT : Select the Baud Rate / DATA bit / Parity / Stop Bit. [RS-485 INPUT SETUP] ▪ SERIAL TYPE : Select external device. ▪...
5.5.3 DDNS ▪ DDNS SERVER : Select DDNS server. ( ezddns.com / dyndns.com / changeip.com ) ▪ HOST NAME : Input the host name from the registered on DDNS server. ▪ USER NAME : Input the user name from the registered on DDNS server. ▪...
5.5.4 E-MAIL [ADDRESS] ▪ SEND E-MAIL : Select On/Off for use. ▪ SCHEDULE : Set the usage time. (From : Start time / To : End time) ▪ E-MAIL ADDRESS : Input the E-mail address to receive. [SERVER] ▪ MAIL SERVER : Select the mail server. (SMTP server / DVR System) ▪...
5.6 SYSTEM INFOMATION In this menu, there are System Log, Status, Version. On the Top menu, select the [INFORMATION] menu icon. 5.6.1 SYSTEM LOG ▪ Check the system log by the left, right direction button.
5.6.2 STATUS [DISK] ▪ Display HDD Status. ▪ CHECK SMART NOW : Check the smart. ▪ SMART INFORMATION : Show the smart information. ▪ SMART INFORMATION : Show the smart information. [RECORD] ▪ Display RECORD Status.
6. SEARCH On the Top menu, select the [SEARCH] menu icon. After select the menu, the following Log-in window will be appeared. Enter the password by the key buttons and press the ENTER button. (The default password : 1) ▪ QUICK SEARCH : Designated time search by User ▪...
6.1 Search Screen Execution Information Message Camera Name Search Information Search Icon Icon Search Screen Repeat Time Information Screen Expand/Reduction Window Backup Progress (%) Recorded Audio Search Date/Time Information Icon 6.1.1 Search Menu When mouse cursor is placed over on the bottom side, the Search menu is appeared. Division Screen Play 1 frame backward Fast forward play...
6.1.2 CALENDAR SEARCH a. Select the data by the direction button. - Recorded data is displayed the orange color. b. Select the time by the direction button. - After select hour, minutes will be appeared. NOTE: The time graph color is different by the recording mode. Continuous Recording = Blue, Audio Recording = Light Blue, Event Recording = Red.
6.1.3 EVENT SEARCH ▪ DATA : Select Date to search. ▪ MOTION : Select On/Off event for search. ▪ ALARM IN : Select On/Off event for search. ▪ VIDEO LOSS : Select On/Off event for search. ▪ SELECT CAMERA : Select the camera for search. ▪...
6.1.4 OVERLAPPED LIST ▪ If user change the time or applied DST (Daylight Saving Time), there will be overlapped data. ▪ After select the list, if select the [PLAY] button, can search [QUICK SEARCH] or [EVENT SEARCH].
6.1.5 PANORAMA SEARCH ▪ During normal search, press the [PANORAMA] button. ▪ By mouse, click the right mouse button and click the [PANORAMA] Search. ▪ Playback with frame by frame. 6.1.6 SMART SEARCH ▪ During normal search, press the [SMART] button. ▪...
6.1.7 SECTION REPEAT SEARCH ▪ During normal search, press the [LOCK] button. When press one time, the start position is set, press one more time, the end position is set. ▪ By mouse, click the below red circle button. ▪ Only playback the set section repeatedly. ▪...
Page 64
※ Button Explanation in Search mode ▪ Remote Controller or Front button Button Explanation SEARCH Display the [SEARCH] menu. Cancel the Search mode or return to the live screen. ENTER Select the CAMEO menu. FAST REVERSE When reverse play, up and down play speed. FAST FORWARD When forward play, up and down play speed.
7. BACKUP On the Top menu, select the [BACKUP] menu icon. After select the menu, the following Log-in window will be appeared. Enter the password by the key buttons and press the ENTER button. (The default password : 1) ▪ TARGET : Select the device to backup. (USB / DVD) ▪...
7.1 Playback with backup data ▪ After backup, the DVR Player is copied with data. ▪ After backup, the DVR Player is copied with data. ▪ Backup data only can be played on DVR Player at PC. ▪ Can export to JPEG still shot.
8. APPENDIX 8.1Trouble Shooting SYMPTOM MEASURES If the power LED is not lighted, check the below items. No Power - Check the power plug and outlet. (Refer to the [Cautions for safety] - Connect the power cord to the power connector of DVR properly. - Connect the camera cable to the DVR port properly.
Page 68
- Check the battery polarity. - Check the remote controller ID. (Refer to the [Remote Controller Configuration]) Not work remote controller - Focus on the remote controller to the IR sensor. - Use the remote controller within 7 meters from DVR. - Change the battery.
