Type The corresponding HDD property.
Total space The HDD total capacity.
Free space The HDD free capacity.
Status HDD can work properly or not.
Bad track Display there is bad track or not.
Page up Click it to view previous page.
Page down Click it to view the next page.
View Click it to view HDD record information (file start time and end time).
recording time
View HDD Click it to view HDD property, status and etc,
type and
capability

5.5.2 BPS

Here is for you to view current video data stream (KB/s) and occupied hard disk storage (MB/h).
See Figure 5-10.
For the 32-channel series product, the interface is shown as below. See Figure 5-11.
Figure 5-10
81
