SWIFT40.

INSTALLING THE AILERON SERVO.

Install the aileron servo into the servo
mount, with the output shaft towards the lead-
ing edge of the wing, using the wood screws
provided with your radio system. Drill 1/16"
pilot holes through the mount before installing
the screws. This will prevent the wood from
splitting.
6
Instruction Manual.
INSTALLING THE AILERON LINKAGE.
Pen.

INSTALLING THE MAIN GEAR WIRES.

1) The blind nuts for securing the landing
gear are already mounted inside the fuselage.
2) Using the hardware provided, mount
the main landing gear to the fuselage.
3) Place the fuselage inverted on the work-
bench in a suitable stand. Set the landing gear
in place and use a screwdrive to secure the
landing gear to the fuselage using bolts
M4x20mm and washers. Make sure to use the
threadlock on the bolts so they don't vibrate
loose.
Wire keeper.
8mm
Wire keeper.
Pushrod
wire.
