System Board Connectors

This section details connectors located on the Workstation 4 system board.

Magnetic Stripe Interface

The internal magnetic card reader connector is CN10, located on the system
board. The pin-outs for this connector are shown in Figure B-10,
Figure B-10: System Board Magnetic Card Reader Connector
Workstation 4 Setup Guide
Connector and Cable Diagrams
System Board Connectors
B-7
