UG-402

ORDERING INFORMATION

BILL OF MATERIALS

Table 5.
Qty Reference Designator
5 P1, P3, P5, P7, P9
5 P2, P4, P6, P8, P10
2 U1, U2
6 D1 to D6
1 1 T1
1 T2
1
1 1 T3
1 1 T4
4 C2, C3, C8, C9
3 C1, C4, C7
4 C10 to C13
3 L1 to L3
2 R1, R28
2 R2, R29
2 R3, R30
2 R6, R32
1 R4
1 R5
1 R17
1 R16
5 R19, R22, R24, R26, R10
0 R11 to R15, R18, R20, R21, R23, R25, R27,
R31, R33 to R40, C5, C6, C14, C15
1 The board is populated with either Coilcraft or Halo transformers. Do not populate both T1 and T2 or T3 and T4.
Description
TP-104 series test point, black
TP-104 series test point, red
ADuM3070
Schottky barrier rectifier, 0.5 A, 40 V, SMD, SOD-123
Transformer, 1:2 turns ratio, SMD
Transformer, 1:2 turns ratio, SMD
Transformer, 1:3 turns ratio, SMD
Transformer, 1:3 turns ratio, SMD
Capacitor ceramic, X7R, SMD, 0603, 0.1 µF
Capacitor ceramic, X7R, SMD, 1210, 47 µF, 20%, 10 V
Capacitor ceramic, X7R, SMD, 1210, 22 µF, 20% 16 V
Inductor, SMD 1212, 47 µH, 20%, 1.25 Ω
RES chip, SMD 0805, 300 kΩ, 1/8 W, 1%
RES chip, SMD 0805, 150 kΩ, 1/8 W, 1%
RES chip, SMD 0805, 100 kΩ, 1/8 W, 1%
RES chip, SMD 0805, 10.5 kΩ, 1/8 W, 1%
RES chip, SMD 0805, 14.3 kΩ, 1/8 W, 1%
RES chip, SMD 0805, 17.4 kΩ, 1/8 W, 1%
RES chip, SMD 0805, 24.9 kΩ, 1/8 W, 1%
RES chip, SMD 0805, 90.9 kΩ, 1/8 W, 1%
RES chip, SMD 0805, 0 Ω, 1/8 W
Not populated
Rev. 0 | Page 10 of 12
Evaluation Board User Guide
Supplier/Part Number
Components Corp./TP-104-01-00
Components Corp./TP-104-01-02
Analog Devices, Inc.
ON Semi/MBR0540
Halo/TGSAD-260V6LF
Coilcraft/JA4631-BL
Halo/TGSAD-290V6LF
Coilcraft/JA4650-BL
AVX/0603YC104KAT2A
Murata/GRM32ER71A476KE15L
Murata/GRM32ER71C226KE18L
Murata/LQH3NPN470MM0
Yageo/RC0805FR-07300KL
Yageo/RC0805FR-07150KL
Panasonic/ECG/ERJ-6ENF1003V
Panasonic/ECG/ERJ-6ENF1052V
Panasonic/ECG/ERJ-6ENF1432V
Panasonic/ECG/ERJ-6ENF1742V
Panasonic/ECG/ERJ-6ENF2492V
Panasonic/ECG/ERJ-6ENF9092V
Panasonic/ECG/ERJ-6GEY0R00V
N/A
