IB0824YC/CVD885 SERIES REMOTE AIR COOLED
MACHINES AFTER SERIAL NUMBER 110682385
NOTE: These characteristics may vary depending on
operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Cycle Time
Air Temp.
Entering
Condenser
°F/°C
-20 to 70/
-29 to 21
80/27
90/32
100/38
1
Times in minutes.
24-HOUR ICE PRODUCTION
Air Temp.
Entering
Condenser
°F/°C
-20 to 70/
-29 to 21
90/32
100/38
110/43
1
Based on average ice slab weight of 5.75-6.50 lb.
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
-20 to 50/
-29 to 10
70/21
80/27
90/32
100/38
110/43
Part Number 80-1505-3 6/11
Freeze Time
Water Temperature °F/°C
50/10
8.9-10.3
10.3-11.9
11.1-12.8
12.2-14.0
50/10
795
700
655
605
Freeze Cycle
Discharge
Pressure Pressure
psig
230-260
250-275
260-290
265-300
300-370
310-385
70/21
9.8-11.2 10.9-12.5
10.5-12.1 12.3-14.1
12.1-13.8 13.0-14.9
13.0-14.9 14.0-16.0
Water Temperature °F/°C
70/21
735
690
610
570
Suction Discharge
Pressure
psig
45-25 180-205
55-30 180-205
60-31 185-215
60-32 190-220
70-34 200-250
75-35 230-260
Harvest
Time
90/32
.75-2.5
90/32
670
600
570
535
Harvest Cycle
Suction
Pressure
psig psig
60-80
75-105
80-110
80-110
90-115
95-115
251
