Manitowoc S1470C Instructions

Manitowoc Models S600C, S1470C
These instructions will help the location manager or machine installer to correctly center the urethane logo on the front panel of the
Manitowoc ice machine.
Tools Needed:
Philips head screw driver
Contents of Kit:
Small packet containing alcohol prep pad
Urethane logo
L-shaped static cling template
MODEL - SY0674C or SD0672C
Follow these instructions to remove the left section of the ice
machine front panel from the machine.
(1) If your machine is on a drink dispenser, remove the drink
dispenser ice bin cover.
(2) Remove the Philips head screw from lower section of the
front panel.
(3) Depress pin to release front panel.
Pictured: S600C
Manitowoc Ice, Inc.
th
2110 South 26 Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA
Telephone 920-682-0161, Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879
Web Site - www.manitowocice.com
KFC and Taco Bell Logo Application Instructions
MODELS - SY1474C or SD1472C
Follow these instructions to remove the ice machine front panel
from the machine.
(1) If your machine is on a drink dispenser, remove the drink
dispenser ice bin cover.
(2) Remove the Philips head screw from lower section of the front
panel.
(3) Pull front panel away from machine while lifting slightly.
000002851
Rev 01
5/25/10
