SD0872C/CVD0885 SERIES REMOTE AIR COOLED
MACHINES AFTER SERIAL NUMBER 110682385
NOTE: These characteristics may vary depending on
operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Cycle Time
Air Temp.
Entering
Condenser
°F/°C
-20 to 70/
-29 to 21
90/32
100/38
110/43
1
Times in minutes.
24-HOUR ICE PRODUCTION
Air Temp.
Entering
Condenser
°F/°C
-20 to 70/
-29 to 21
90/32
100/38
110/43
1
Based on average ice slab weight of 5.75-6.50 lb.
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
-20 to 50/
-29 to 10
70/21
80/27
90/32
100/38
110/43
Part Number 80-1505-3 6/11
Freeze Time
Water Temperature °F/°C
50/10
8.7-10.0
10.0-11.5
10.9-12.5
11.9-13.6
50/10
815
720
670
620
Freeze Cycle
Discharge
Pressure Pressure
psig
200-250
250-290
260-300
270-310
300-380
310-390
70/21
9.6-11.1 10.7-12.3
10.2-11.8 12.0-13.7
11.7-13.5 12.8-14.6
12.7-14.5 13.6-15.5
Water Temperature °F/°C
70/21
745
705
625
585
Suction Discharge
Pressure
psig
50-30 170-200
60-30 180-210
60-31 190-220
60-33 200-230
80-34 210-250
80-35 220-260
Harvest
Time
90/32
.75-2.5
90/32
680
615
580
550
Harvest Cycle
Suction
Pressure
psig psig
65-75
75-95
75-95
80-100
90-110
105-130
247
