Symptom #4 Ice Will not Harvest - Cubes Are Melted Flowchart

Ice Machine Will Not Harvest - Freeze Cycle Is Normal and Ice Cubes Are Melted After Harvest
Back of cubes are melted
at end of harvest cycle?
NO NO
Ice remains frozen to the
evaporator at the end of the
harvest cycle?
YES
YES
Refer to
Refrigeration
Analysis Chart
Is Ice Machine level?
YES
Is water flow over the evaporator at
the end of harvest cycle?
NO
Level Ice
NO
Machine
Refer to
YES Dump Valve
Diagnostics
Continued on Next Page...
