Installing The Elevator Pushrod - Phoenix Model CLASSIC-EP Instruction Manual

33
a1
Check the fin before it dry and remove the wing out of the
fuselage.
4

Installing the elevator pushrod.

Installing the elevator pushrod.
34
The elevator and rudder linkages.
36
Cut away the screw.
38
Install the clevis to the aileron pushrod.
a2
a1 = a2
35
Secure the control horn onto the elevator.
37
Remove the covering from the slot.
39
Insert the silicon tube into the clevis.
6
