Phoenix Model CLASSIC-EP Instruction Manual page 5

17
Attach the nylon clasp to the aileron servo arm.
3 Installing the horizontal and vertical stabilizer.
19
Make a center line onto the horizontal.
21
Attach the horizontal to the fuselage and check it.
23
Mark the shape of the fuselage onto the bottom of the
horizontal.
18
Nylon clasp
Make the same way for the second aileron pushrod.
20
Remove the covering from the fuselage.
22
Mark the shape of the fuselage onto the top of the horizontal.
24
Remove the covering from the top and the bottom of the
horizontal.
4
