Phoenix Model TIGER MOTH Instruction Manual

TIGER MOTH
GP/EP Size 30-35CC SCALE 1:6 ¼ ARF
SPECIFICATION
- Wingspan: 2270mm (89.4in)
- Length: 1870mm (73. 6 in)
- Flying weight: 8.4-8.9 kg
- Wing area: 154 dm2
- Wing loading: 69g/dm2
- Wing type: Naca profile
- Covering type: OraCover
- Spinner size: scale type (not included)
- Radio: 4 channel minimum (not included)
- Servo: 6 standard hi-torque servo: 2 aileron;
2 elevator; 1 rudder; 1 throttle (not included)
- Recommended receiver battery:
4.8-6V / 1200-2000mAh NiMH (not included)
- Propeller: suit with your engine
- Engine: 30-35cc gas engine (not included)
Instruction Manual
- Motor: brushless outrunner 2500 W,
- Gravity CG: 190 mm (7.5 in) Back from the
- Control throw Ailerons: Low: 15mm up/down,
- Control throw Elevators: Low: 12mm up/down,
- Control throw Rudder: Low: 35mm right/left,
- Experience level: Intermediate
- Plane type: Scale Civilian
RECOMMENDED MOTOR AND BATTERY SET UP
- Motor: RIMFIRE 1.60 (not included)
- Lipo cell: 12 cells / 5000 – 6000mAh (not included)
- Esc: 120-160A (not included)
250 KV (not included)
leading edge of the upper wing, at the fuselage
10% expo; High: 20mm up/down, 10% expo
12% expo; High: 15mm up/down, 12% expo
15% expo; High: 45mm right/left, 15% expo
GP EP
version version
