IP28
NOTE: If installing the Modular Faceplate with the mock fi replace applica-
tion - adjust the framing tabs accordingly
1) Remove the stabilizer bar by removing 4 screws - install the convention
air duct in the same location using the same 4 screws, see below.
2) Install four (4) screws in locations shown below to secure faceplate
Regency IP28 Gas Inbuilt Fireplace
918-973a
MODULAR FACEPLATE INSTALLATION
MODULAR FACEPLATE INSTALLATION
3) Hook up wire harness from faceplate to connection to under unit and
check gas connections.
4) Reinstall bottom louver and install 2 screws in locations shown below
5) Re install front frame.
6) Final install.
2
INSTALLATION
29
05/02/12
