Regency U31 Owners & Installation Manual

Gas insert zero clearance kit
Hide thumbs Also See for U31:

Advertisement

Quick Links

Owners &
Installation
Tested by:
Warnock Hersey
& AGA
U31/I31 GAS INSERT
ZERO CLEARANCE KIT
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property dam-
age. Refer to this manual.
assistance or additional information
consult an authorized installer, serv-
ice agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapours and liquids in
the vicinity of this or any other appli-
ance.
Installation and service must be per-
formed by an authorized installer,
service agency or the gas supplier.
908- 005
KIT # 410- 905
FOR YOUR SAFETY
What to do if you smell gas:
! ! ! ! ! Do not try to light any
For
appliance
! ! ! ! ! Do not touch any electri-
cal switch: do not use
any phone in your build-
ing.
! ! ! ! ! Immediately call your
gas supplier from a
neighbour's
Follow the gas suppli-
er's instructions.
! ! ! ! ! If you cannot reach your
gas supplier, call the fire
department.
phone.
01/08/09

Advertisement

Table of Contents
loading

Summary of Contents for Regency U31

  • Page 1 U31/I31 GAS INSERT Owners & ZERO CLEARANCE KIT Installation KIT # 410- 905 PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, What to do if you smell gas: alteration, service or maintenance ! ! ! ! ! Do not try to light any can cause injury or property dam- age.
  • Page 2: Table Of Contents

    Kit Assembly ................. 7 Venting (Flueing) ..............8 Optional Outside Combustion Air Supply Installation ... 9 Gas supply line ..............9 Electrical Supply ..............9 Faceplate & Trim Installation ..........10 Finished Facing Notes ............11 U31/I31 Gas Insert Zero Clearance Kit...
  • Page 3: Listings And Code Approvals

    This kit consists of factory built parts that require minimal Included with Kit: assembly to form the Zero Clearance enclosure for the U31/ 1 (410- 905) Main Body Assembly I31 Gas Insert. The enclosure can then be fixed into a framed...
  • Page 4: Clearances To Combustibles

    508mm to 5.5" to 140mm 21" 533mm to 12" to 305mm 22" 559mm Max. Top View **Max. width of 1"(25mm) at 1"(25mm) from surround, calcu- late depth at 45 as shown in the diagram. U31/I31 Gas Insert Zero Clearance Kit...
  • Page 5: Locating Your Fireplace

    ASH LIP FOR FLUSH INSTALLATION An ashlip is mandatory on a U31/I31 Flush (flat window) Insert when installed less than 6" (152mm), (including the 4"(102mm) Hearth Trim) to a combustible floor (see Figure 1). For detailed installation see Faceplate and Trim Installation.
  • Page 6: Ashlip Installation

    For exterior walls, vapour barrier and insulate the enclosure to the same degree as the rest of the house, or according to local installation codes. The appliance may be enclosed above the standoffs on the cabinet but the clearances stated on the "B- vent" chimney must be maintained. U31/I31 Gas Insert Zero Clearance Kit...
  • Page 7: Kit Assembly

    Leakage in this area will result in possible overheat- ing of the finishing material im- mediately above the frame. See diagram 1. Diagram 1 Diagram 2 Diagram 3 U31/I31 Gas Insert Zero Clearance Kit...
  • Page 8: Venting (Flueing)

    CAN/CGA - B149 (Canada), ANSI Z223.1 Install stove insert as per U31/I31 Installation Manual. (U.S.A.), AG 601 (Australia), and NZS 5261 (New Zea- land). Minimum chimney height from base of fireplace must be at least 12 feet (3.6m).
  • Page 9: Optional Outside Combustion Air Supply Installation

    The suggested way to install the gas supply line is as follows: run 1/2" (9.5 mm) NPT gas line to the left side of the framed opening. (See U31/I31 installation instructions for additional information).
  • Page 10: Faceplate & Trim Installation

    POWER CORD (3ft) Diagram 3 The power cord should be run behind the faceplate panel from the U31/I31 to electrical outlet box. Diagram 1: Faceplate Assembly Using the trim clips provided, join the left side trim (with the ON/OFF switch) to the top trim. See diagram 2.
  • Page 11: Finished Facing Notes

    If ashlip is required for safety clearance (see pg. 5) then attach to stove unit using the 2 lower screw holes on the face of the stove unit (see diagram 6 detail 'B'). Note: This faceplate with Hearth Trim Assembly replaces the standard Assembly as shown in the U31/I31 Installation Manual. FINISHED FACING NOTES Install finished facing surface of 1/2"(13mm) thickness on framing.
  • Page 12 Fireplace Products Australia Pty. Ltd. 21-23 South Link, Dandenong South Victoria, 3175 Australia FPI Fireplace Products International Ltd. 6988 Venture St., Delta, B.C. Canada, V4G 1H4 © Copyright 2011, FPI Fireplace Products International Ltd. All rights reserved. Printed in Canada...
