NOTE: If installing the Low Profi le Faceplate with the mock fi replace - ad-
just the framing tabs accordingly
1) Remove the stabilizer bar by removing 4 screws - install the convention
air duct in the same location using the same 4 screws, see below.
2) Install four (4) screws in locations shown below to secure faceplate
Regency IP28 Gas Inbuilt Fireplace
918-973
SLIM LINE FACEPLATE INSTALLATION
LOW PROFILE FACEPLATE INSTALLATION
3) Hook up wire harness from faceplate to connection to under unit and
check gas connections.
4) Reinstall bottom louver and install 2 screws in locations shown below
5) Re install front frame.
6) Final install.
1
IP28
INSTALLATION
27
12/16/10
