I1200S
Wood Insert
www.regency-fi re.com
Owners & Installation Manual
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
918-665a
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
07/30/08
Advertisement
Table of Contents
Related Manuals for Regency I1200S
Summary of Contents for Regency I1200S
- Page 1 I1200S Wood Insert www.regency-fi re.com Owners & Installation Manual Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. 918-665a FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4...
- Page 2 The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the REGENCY DEALER in your area. Keep those REGENCY FIRES burning.
-
Page 3: Table Of Contents
Fan / Blower ...15 Firebrick Assembly ...16 Draft Control ...16 Door Handle ...16 Brick Flue Baffl e & Secondary Air Tube Installation ...16 Screen Door ...17 I1200 Regency Wood Insert TABLE OF CONTENTS OPERATING INSTRUCTIONS First Fire ...17 Fan Operation...18 Ash Disposal...18 Some Safety Guidelines ...18... -
Page 4: Safety Label
SAFETY LABEL This is a copy of the label that accompanies each I1200S Wood Insert. We have printed a copy of the contents here for your review. NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 5: Unit Dimensions
UNIT DIMENSIONS WITH STANDARD FLUE ADAPTOR 6" (152mm) Diameter STANDARD FLUE ADAPTOR (171-932) I1200 Regency Wood Insert... -
Page 6: With Offset Flue Adaptor
UNIT DIMENSIONS WITH OFFSET FLUE ADAPTOR 6" (152mm) Diameter OFFSET FLUE ADAPTOR (171-936) I1200 Regency Wood Insert... -
Page 7: Installation
National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical code, CSA C22.1. Regency Inserts are designed with a 6" (152mm) fl ue. This insert must be connected to a code-ap- proved masonry chimney or listed factory-built fi... -
Page 8: Masonry And Factory Built Fireplace Clearances
R is greater than required, the system is acceptable. Minimum Minimum Minimum Hearth Hearth Hearth Side Extension* Thickness* Extension 8" (203mm) Floor Protection DEFINITIONS Thermal Conductance: (hr)(ft Thermal Conductivity: (Btu)(inch) (hr)(ft (m)(K) Thermal Resistance: R = (ft )(hr)( )(K) I1200 Regency Wood Insert )(K) (hr)(ft)(... -
Page 9: Installing Your Insert
Secure adaptor using 3 screws - 1 in the front and 1 each on the left and right side. I1200 Regency Wood Insert 3) Install the unit by fi rst setting the rear of the unit into the fi replace. See diagram 3. -
Page 10: Installation Into Amasonry Fireplace
fl exible liner pipe is routed from the insert outlet collar to the top of the chimney. Regency highly recommends the use of a full liner as the safest installation and provides the most optimum performance. Your retailer should be able to help you decide which system would be the best for your application. -
Page 11: Faceplate, Trim & Optional Fan Support Installation
INSTALLATION FACEPLATE, TRIM & OPTIONAL BOTTOM FACEPLATE & FAN SUPPORT INSTALLATION Regular Faceplate Dimensions: Oversize Faceplate Dimensions: I1200 Regency Wood Insert... - Page 12 7) Remove the faceplate assembly from the insert and attach the cut bottom faceplate to the faceplate sides using the 1/4" x 1/2" long hex bolts, lock washers and nuts provided as shown in Diagram 4. Rear View Diagram 4 I1200 Regency Wood Insert...
- Page 13 Diagram 6. Diagram 6: Shown with Optional Bottom Faceplate I1200 Regency Wood Insert 11) Mount the completed faceplate / trim assembly to the insert. Ensure to align the side faceplate slots with the hex bolts in the mounting brackets and tighten to secure in place.
- Page 14 21) Drill two 5/32" diameter holes through the trim and side panels and screw the trim to the panels using the self tapping screws provided as shown in Diagram 6. 22) Re-attach the fan/fan support assembly to the ash lip of the insert. Completed Faceplate Assembly I1200 Regency Wood Insert...
-
Page 15: Fan / Blower
Ground 120V AC 60 Hz Fan Thermodisc (normally open) I1200 Regency Wood Insert FAN / BLOWER Do not turn fan ON until your insert has reached operating temperature or at least 30 minutes after starting fi re. CAUTION: Label all wires prior to disconnection when servic- ing controls. -
Page 16: Firebrick Assembly
fi rebox, just below the fl ue baffl e. WARNING: To build a fi re in ignorance or to disregard the informa tion contained in this section can cause serious permanent dam- age to the unit and void your warranty. I1200 Regency Wood Insert... -
Page 17: Screen Door
fi re and smoke. When operated with doors fully open the manufacturer supplied screen must be used. I1200 Regency Wood Insert FIRST FIRE When your installation is completed and in- spected, you are ready for your fi rst fi re. -
Page 18: Fan Operation
8) Do not permit creosote or soot buildup in the chimney system. Check and clean chimney at regular intervals. 9) Your Regency Insert can be very hot. You may be seriously burned if you touch the insert while it is operating. Warn children of the burn hazard. -
Page 19: Maintenance Of Gold-Plated Doors
GLASS REPLACEMENT Your Regency Insert is supplied with 5 mm. Neoceram ceramic glass that will withstand the highest heat that your unit will produce. In the event that you break your glass by impact... -
Page 20: Parts List
Air Tube - 3/4" (Qty: 1) 38) 073-955 Baffl e (2/set) 47) 846-101 Wood Screen 171-932 Standard Flue Adaptor 171-936 Offset Flue Adaptor 948-216 Regency Logo 918-665 Manual *Not available as a replacement part. MAIN ASSEMBLY I1200 Regency Wood Insert... -
Page 21: Faceplates
Trim Set - Oversize Brass 171-928 Bottom Piece and Fan Support - Regular 171-930 Bottom Piece and Fan Support - Oversize I1200 Regency Wood Insert FACEPLATES 60) * Faceplate Right Side Regular / Oversize 61) * Faceplate Left Side Regular / Oversize... -
Page 22: Firebrick
Brick Partial: 1-1/4" x 2" x 9" 81) * Brick Partial: 1-1/4" x 1-1/4" x 9" 84) * Brick Partial: 1-1/4" x 4-1/2" x 8" 85) * Brick Partial: 1-1/4" x 4-1/4" x 8" *Not available as a replacement part. FIREBRICK I1200 Regency Wood Insert... -
Page 23: Warranty
The authorized selling dealer is responsible for all in-fi eld service work carried out on your Regency product. FPI will not be liable for results or costs of workmanship from unauthorized service persons or dealers. - Page 24 Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency is a trademark of FPI Fireplace Products International Ltd. © Copyright 2009, FPI Fireplace Products International Ltd. All rights reserved. Regency fi replace products are designed with reliability and simplicity in mind. In...
