Owners &
Installation
LISTINGS AND CODE APPROVALS
These gas appliances have been tested in
accordance with AS4553, NZS 5262 and
have been certifi ed by the Australian Gas
Association for installation and operation as
described in these Installation and Operating
Instructions.
Your unit should be serviced annually by
an authorised service person.
IP28 GAS INBUILT
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE
WARNING:
Improper installation, adjustment, altera-
tion, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional in-
formation consult an authorised installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other fl am-
mable vapours and liquids in the vicinity of
this or any other appliance.
Installation and service must be performed
by an authorised installer, service agency or
the gas supplier.
918-938a
Models:
REFERENCE
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appli-
ance
Do not touch any electri-
cal switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the fi re
department.
IP28-NG
IP28-PROPANE
06/07/11
Advertisement
Table of Contents
Related Manuals for Regency IP28-NG
Summary of Contents for Regency IP28-NG
- Page 1 Owners & Installation IP28 GAS INBUILT Models: IP28-NG IP28-PROPANE PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, altera- What to do if you smell gas: tion, service or maintenance can cause Do not try to light any appli- injury or property damage.
- Page 2 GAS INBUILT FIREPLACE TO THE NEW OWNER Congratulations! You are the owner of a state-of-the-art Gas Inbuilt Fireplace by FPI. The Regency Gas Fireplace Series of appliances has been designed to provide you with all the warmth and charm of a fi replace, at the fl ick of a switch. The model IP28 of this series has been approved by Australian Gas Association for both safety and effi...
- Page 3 DIMENSIONS UNIT DIMENSIONS W/ CONTEMPORARY FACEPLATE 27.298 (694mm) 37.150 (944mm) Regency IP28 Gas Inbuilt Fireplace...
-
Page 4: Copy Of Data Badge
DIMENSIONS UNIT DIMENSIONS W/ SLIM LINE FACEPLATE 27-5/16” (693mm) 40-1/2” (1030mm) Regency IP28 Gas Inbuilt Fireplace... - Page 5 DIMENSIONS DIMENSIONS - OPTIONAL MODULAR FIREPLACE SOLUTION 50-3/16” (1275mm) 18-5/16”(465mm) 49”(1245mm) Regency IP28 Gas Inbuilt Fireplace...
-
Page 6: Table Of Contents
Glass Door installation..........22 Main Assembly ............37 Contemporary faceplate Installation ......23 Contemporary Faceplate Assembly......38 Hearth trim Installation..........24 Slim line Faceplate Assembly ........38 Slim line faceplate Installation ........25 Final Check..............26 WARRANTY Wiring ................26 standard WIRING ............26 Warranty ..............39 Regency IP28 Gas Inbuilt Fireplace... -
Page 7: Data Badge
SAFETY LABEL This is a copy of the label that accompanies each Regency IP28 Gas Inbuilt fi replace. We have printed a copy of the contents here for your review. DATA BADGE NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 8: Installation
INSTALLATION IMPORTANT MESSAGE BEFORE YOU START The Regency Gas Inbuilt must be installed in ac- INSTALLATION AND REPAIR SHOULD cordance with these instructions. Carefully read all BE DONE ONLY BY AN AUTHORISED the instructions in this manual fi rst. PERSON. -
Page 9: Minimum Fireplace Opening Dimensions
15-1/8” (384mm) (SLIM LINE FASCIA) Mantel Clearances 490mm The minimum fi replace dimensions for the Regency gas space heater when using the Slim line Fascia are shown in the following diagrams: NOTE: ALLOW FOR SIDE GAS CONNECTION (For Slim line Fascia) -
Page 10: Optional Modular Fi Replace Solution Clearances
INSTALLATION OPTIONAL MODULAR FIREPLACE SOLUTION CLEARANCES 36” 51-7/16” (1305mm) (914mm) 51-7/16” (1305mm) 39-3/8” (1000mm) 1-7/16” (37mm) 25-7/8” (655mm) 33-7/16” (848mm) Regency IP28 Gas Inbuilt Fireplace... -
Page 11: Mock Fireplace Kit (Zero Clearance) Installation
Back standoffs x 2 Side standoffs x 2 1 on each side NOTE: Please adjust nailing fl anges in relationship to either Contemporary or Slim line Faceplate. Faceplate needs to be fl ush against fi nished wall. Regency IP28 Gas Inbuilt Fireplace... -
Page 12: Gas Pipe Pressure Testing
6) When fi nished reading manometer, turn off the gas valve, disconnect the hose and tighten the screw (clockwise) with a 1/8" fl at screwdriver. Screw should be snug, but do not over tighten. Install to AS5601 (Australia) / NZS 5262 (New Zealand) Regency IP28 Gas Inbuilt Fireplace... -
Page 13: Exterior Flue Termination Locations
(IV) A fl ue terminal of this type shall not be located under a roofed area unless the roofed area is fully open on at least two sides and a free fl ow of air at the appliance is achieved. Regency IP28 Gas Inbuilt Fireplace... -
Page 14: Venting And Termination
Be sure not to damage the gasketing. Ensure both the inner and the outer are fl ush on the ‘’terminal side’’ and measurements are correct. Once the venting is properly secured to the unit at the correct measurements for the cavity, the unit is now ready for installation. Regency IP28 Gas Inbuilt Fireplace... -
Page 15: Aeration Settings
(Close the aeration for a more yellow fl ame, or open it to make the fl ame bluer). 7.94mm open 15mm open Note: Any damage due to carboning resulting from improperly setting the aeration is NOT covered under warranty. Regency IP28 Gas Inbuilt Fireplace... -
Page 16: Conversion Kit For Ng To Lpg Model
When adjusting maximum pres- sure do not screw the nut in fully. If unable to obtain 2.49kPa outlet, check inlet pressure is adequate. Damage may occur to the gas valve if maximum pressure adjustment is fully screwed in. Regency IP28 Gas Inbuilt Fireplace... -
Page 17: Optional Modular Fireplace Solution Install
3) Ensure venting is secured to unit and slide unit carefully into the MFS. NOTE: SLIDE UNIT IN PARTIALLY TO ALLOW ACCESS TO CONNECT GAS AND ELECTRICAL. Once gas and electrical are connected, slide unit in completely. Regency IP28 Gas Inbuilt Fireplace... - Page 18 See installation manual for detailed instructions. Install decorative log kit as referenced in the installation manual. 6) Install the faceplate as referenced in the installation manual, under slimline faceplate. 7) Ensure the proper gas pressure. Regency IP28 Gas Inbuilt Fireplace...
-
Page 19: Optional Stainless Steel Inner Panel Install
Final installation of optional stainless panels. Orient the stainless side panels with the angled corner facing the back of the fi rebox. Angled corner in panel Regency IP28 Gas Inbuilt Fireplace... -
Page 20: Switch Operation
ON | OFF | REMOTE HIGH | LOW (FAN) HIGH | LOW (Mj) HIGH | LOW (FAN) ON | OFF | REMOTE HIGH | LOW (Mj) Switch operation - Slim line Faceplate Switch operation - Contemporary Faceplate Regency IP28 Gas Inbuilt Fireplace... -
Page 21: Log Set Installation
Install left front log (0115). Place lava rocks on fi rebox base in front of logs - do not block porting and spread out evenly. Install right front log (0115). Final install. Regency IP28 Gas Inbuilt Fireplace... -
Page 22: Glass Door Installation
4) With new glass installed in correct position, reinstall all glass retainers and screws. Ensure all screws are tightened to create a proper seal. Do not over tighten. NOTE: Unit will not operate with glass removed Regency IP28 Gas Inbuilt Fireplace... -
Page 23: Contemporary Faceplate Installation
Install four (4) screws in locations shown below to secure faceplate 5) Final install. 2) Hook up wire harness from faceplate to connection to under unit and check gas connections. 3) Reinstall bottom louver and install 2 screws in locations shown below. Regency IP28 Gas Inbuilt Fireplace... -
Page 24: Hearth Trim Installation
Line up the hearth trim with the bottom of the fascia until it is fl ush with the fascia. From the backside of the fascia - secure the hearth trim with 3 screws on each side in locations shown below. Regency IP28 Gas Inbuilt Fireplace... -
Page 25: Slim Line Faceplate Installation
4 screws, see below. 4) Reinstall bottom louver and install 2 screws in locations shown below 5) Re install front frame. 2) Install four (4) screws in locations shown below to secure faceplate 6) Final install. Regency IP28 Gas Inbuilt Fireplace... -
Page 26: Final Check
YELLOW BLACK GREY PURPLE PURPLE BLUE 911-040 ORANGE ORANGE BROWN BROWN BROWN 240V PLUG ORANGE BROWN BLACK WHITE PURPLE BLUE BLUE BLUE YELLOW/GREEN GAS CONTROL ROOM FAN GROUND BROWN BLUE BLUE BLUE YELLOW/GREEN COMBUSTION FAN Regency IP28 Gas Inbuilt Fireplace... -
Page 27: Operating Instructions
This will burn off after a few minutes of operation. REMOTE CONTROL LIGHTING Use the Regency Remote Control Kit approved for this unit. Use of other systems may void your INSTRUCTIONS warranty. 1) Locate the 3 way switch located on the face-... -
Page 28: Remote Receiver Installation
Once you connect the black wire, the other 2 wires are identifi ed by the male-female connec- tor. Place the receiver in the left hand side on the base of the heater. Ensure the receiver aerial is not touching metal components. Regency IP28 Gas Inbuilt Fireplace... -
Page 29: Copy Of Lighting Instruction Plate
NOTE: Wait 2 minutes between reset attempts. Appliances incorporating a live fuel effect (designed to oper- " ate with blue fl ames with slight yellow tips) may exhibit slight carbon deposition." Regency IP28 Gas Inbuilt Fireplace... - Page 30 Check the combustion fan & pressure switch are operating (there should be an audible click when the pressure switch makes contact). Providing the spill switch has continuity the electrode should spark and the gas valve open within 5 seconds of the completion of the purge cycle. Regency IP28 Gas Inbuilt Fireplace...
-
Page 31: Maintenance
The heater is fi nished in a heat resistant paint and should only be refi nished with heat resist- Your Regency stove is supplied with high tem- ant paint (not with wall paint). Regency uses perature, 5 mm Neoceram ceramic glass that WARNING: FAILURE TO INSTALL THIS StoveBright Paint - Metallic Black #6309. -
Page 32: Convection Fan Replacement
4) Remove 2 wing nuts + washers securing fan - locations shown below. 5) Unclip wires from base of unit and unplug fan. 6) Disconnect polarized plug. 7) Manoeuvre fan from base of unit and replace. Regency IP28 Gas Inbuilt Fireplace... -
Page 33: Combustion Fan Replacement
4) Remove convection fan - see previous page. 5) Remove 4 screws to release fan. 9) Reverse steps to reinstall. 6) Disconnect polarized plug. 7) Disconnect tubing from right side of fan. Tubing 8) Disconnect ground wire. Regency IP28 Gas Inbuilt Fireplace... -
Page 34: Pressure Switch Replacement
NOTE: It is important to label wires and hose connections to ensure the new switch is hooked up in the same manner. Remove the two screws on the mounting bracket. Remove 2 screws Slide switch out to the left side. Remove switch and replace. Reverse steps to complete installation. Regency IP28 Gas Inbuilt Fireplace... -
Page 35: Valve Assembly Replacement
3) Open the bottom louvre to access valve. 6) Disconnect wire harness plug. 4) Remove screw in location shown below to release valve cover. 7) Remove screw from rectifi er, 5) Partially lift out valve cover. 8) Unplug rectifi er from valve. Regency IP28 Gas Inbuilt Fireplace... - Page 36 MAINTENANCE 9) Disconnect ground wire from valve. 10) Disconnect connection from valve to burner. 11) Disconnect connection from valve to gas outlet. 12) Remove valve and replace. 13) Reverse steps to reinstall. Regency IP28 Gas Inbuilt Fireplace...
-
Page 37: Parts List
Power Cord Assembly 240V IP28 918-938 Manual 456-001 Grate Assembly IP28 456-044/F Bracket side fl ange right / IP28 456-049/F Bracket side fl ange left / IP28 *Not available as a replacement part. ** Part not shown. Regency IP28 Gas Inbuilt Fireplace... -
Page 38: Contemporary Faceplate Assembly
Door Bottom Access Slim F/P IP28 Frame Front Slim Faceplate IP28 Faceplate Front IP28 911-043 Wire Harness Control Switch IP28 911-060 Switch Rocker TC201-TB-B On/Off/On 911-061 Switch Rocker TB201-TB-B On/None/On *Not available as a replacement part. Regency IP28 Gas Inbuilt Fireplace... -
Page 39: Warranty
Regency shall in no event be liable for any special, indirect consequential damages of any nature whatsoever which are in excess of the original purchase price of the product. Any alteration to the unit which causes sooting or carboning that results in damage to the exterior facia is not the responsibility of Regency Fireplace Products. - Page 40 FIREPLACE PRODUCTS AUSTRALIA PTY. LTD. 21-23 SOUTH LINK, DANDENONG SOUTH VICTORIA, 3175 AUSTRALIA © Copyright 2010, FPI Fireplace Products International Ltd. All rights reserved. Printed in Canada...
