Regency Cascades I1500 Owners & Installation Manual

Wood insert
Hide thumbs
Table of Contents

Advertisement

Quick Links

Cascades™
I1500
Wood Insert
Owners & Installation Manual
www.regency-fire.com
French Manual: https://bit.ly/2ykr3O7
Manuel en Français: https://bit.ly/2ykr3O7
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
0219WN025S
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
919-715c
06.09.20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cascades I1500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Regency Cascades I1500

Summary of Contents for Regency Cascades I1500

  • Page 1 Cascades™ I1500 Wood Insert Owners & Installation Manual www.regency-fire.com French Manual: https://bit.ly/2ykr3O7 Manuel en Français: https://bit.ly/2ykr3O7 Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference.
  • Page 2 Model Regency I1500 – 1.0 g /hr. “This manual describes the installation and operation of the Regency I1500 catalytic equipped wood heater. This heater meets the 2020 U.S. Environmental Protection Agency’s crib wood emission limits for wood heaters. Under specific test conditions this heater has been shown to deliver heat at rates ranging from 14,244 BTU/hr to 20,386 BTU/hr.”...

  • Page 3: Table Of Contents

    CAUTION: To avoid burns or wood splinters, when opening/closing the fuel door or adding wood to the fire, You should always wear appropriate protective gloves to protect your hands from the heat being emitted from this fireplace. I1500 Regency Wood Insert...

  • Page 4: Copy Of The Safety Label For I1500

    I1500 Wood Insert. We have printed a copy of U.S. ENVIRONMENTAL PROTECTION AGENCY CERTIFIED TO COMPLY WITH 2020 PARTICULATE EMIS- SION STANDARDS USING CRIB WOOD.” TESTED TO METHOD 28R. MODEL REGENCY I1500 – 1.0G /HR. the contents here for your review.

  • Page 5: Unit Dimensions With Standard Flue Adaptor

    WITH STANDARD FLUE ADAPTOR 6" (152mm) Diameter STANDARD FLUE ADAPTOR *1-1/2" (38mm) *Measurement from back of faceplate to fuel door opening Regency Inserts are designed to use either a 5.5" (140mm) or 6" (152mm) flue. I1500 Regency Wood Insert...

  • Page 6: Unit Dimensions With Offset Flue Adaptor

    WITH OFFSET FLUE ADAPTOR 6" (152mm) Diameter OFFSET FLUE ADAPTOR *1-1/2" (38mm) *Measurement from back of faceplate to fuel door opening Regency Inserts are designed to use either a 5.5" (140mm) or 6" (152mm) flue. I1500 Regency Wood Insert...

  • Page 7: Installation

    Install and use be supplied with appropriate supporting means. only in accordance with manufacturer’s Regency Inserts are designed to use either a installation and operating instructions. 5.5" (140mm) or 6" (152mm) flue. 10. Installer must mechanically attach the supplied label to the inside of the firebox of the fireplace 2.

  • Page 8: Masonry And Factory Built Fireplace Clearances

    Please check to ensure that your floor protection and hearth will meet the standards for clear- ance to combustibles. Your hearth extension must be made from a non-combustible material. Extending 16" for US and 18" for Canada—measured from the fuel loading door. I1500 Regency Wood Insert...
  • Page 9 2. Install flex liner into existing chimney as per liner manufacturer’s specifications. Ensure that the notch on the adapter cut in the previous step is pointed forward at about the 6 o'clock position. See Diagram 1. Diagram 7 Diagram 4 03.24.20 920-051b I1500 Regency Wood Insert...

  • Page 10: Installation Into Amasonry Fireplace

    3. In most cases opening the existing spark screens fully should give enough room for the insert installation. If it does not, remove and store. 10 | I1500 Regency Wood Insert...

  • Page 11: Faceplate, Trim & Optional

    5"W x 0.7"H BOTTOM FACEPLATE & FAN SUPPORT INSTALLATION Regular Faceplate Dimensions (shown with bottom faceplate/fan support attached): 38” (965mm) 38” (965mm) Oversize Faceplate Dimensions (shown with bottom faceplate/fan support attached): 44” (1118mm) 44” (1118mm) I1500 Regency Wood Insert 03/10/19 920-023...
  • Page 12 Tool holder Diagram 2A Diagram 4 If the insert is going to sit on the hearth proceed to "Faceplate Trim Installation" (step 8) otherwise con- tinue on to "Bottom Faceplate Installation" (step 4). 12 | 920-023 03/10/19 I1500 Regency Wood Insert...
  • Page 13 (Black Trim included with Regular/Oversize Faceplate brackets and tighten to secure in place. Secure the Regency logo or Bottom Faceplate) plate to the bottom of the faceplate.
  • Page 14 Diagram 6. 22) Re-attach the fan/fan support assembly to the ash lip of the insert. Diagram 9: Rear / Bottom View Note: Fan not exactly as shown Completed Faceplate Assembly Faceplate Side 14 | I1500 Regency Wood Insert 920-023 03/10/19...

  • Page 15: Fan / Blower

    Ground wire from fan Lockwasher Star washer Star washer Ground wire from power cord Wire98gr.eps updated Jan. 27/00 updated: Aug. 09/05 capitalized the word Nut BLACK BLACK GREEN RHEOSTAT ___l_ -==- GRND THERMODISC Wiring Diagram I1500 Regency Wood Insert 919-719 09.22.16...

  • Page 16: Brick Installation

    4.250 x 8.000 x 30 DEG BRICK 802-147 3.500 x 4.500 BRICK 802-152 2.000 x 9.000 BRICK 902-111 9.000 x 4.500 STANDARD BRICK RD-14289 4.500 x 7.000 BRICK RD-14288 4.250 x 7.000 BRICK ITEM PART NUMBER QTY. DESCRIPTION 16 | I1500 Regency Wood Insert...

  • Page 17: Glass Replacement

    GLASS REPLACEMENT Your Regency stove is supplied with 5 mm Neoceram ceramic glass that will withstand the highest heat that your unit will produce. In the event that you break your glass by impact, purchase your replacement from an authorized Regency dealer only.

  • Page 18: Wood Door & Handle Assembly

    (Refer to Diagram 1) Door hinges Wood handle Door Door handle Hinge Cap Cover Diagram 2 tooltip Diagram 3 18 | I1500 Regency Wood Insert 919-967a 04.03.19...

  • Page 19: Stainless Steel Smoke Deflector Installation

    WARNING: Operation of the unit with out proper installation of smoke deflector will void warranty. Ensure deflector is seated so bolts are seated at the bottom of the slot before tightening. Smoke deflector installed with 2 bolts. Note: This is a cutaway view from the back of the unit I1500 Regency Wood Insert...

  • Page 20: Seasoned Wood

    Split a piece of wood. If the exposed surface feels damp, the wood is too wet to burn. Loosen these two bolts and slide in the bracket. Air and Bypass operating handle/monitor stor- age. 20 | I1500 Regency Wood Insert...

  • Page 21: Operating Instructions

    Regency Stove causing a draft down your diately it may go out or the combustor may stop chimney. If this occurs, slightly open a window working.

  • Page 22: Fan Operation

    During constant use, ashes should be removed every few days. The Ash Drawer option features a 7. Your Regency stove can be very hot. You may be convenient ash dump for easy removal of ash, refer seriously burned if you touch the stove while it is to Modular Installation Options section.

  • Page 23: Maintenance

    Burning coal will cause a sulfur-based compound to coat the catalyst. Revert to burning wood and fire the combustor to elevated temperatures for one hour. Cleaning & Maintaining Your Wood Stove I1500 Regency Wood Insert...

  • Page 24: Maintenance

    If the door gasket requires replacement 5/8" diameter The chimney connector and chimney should be material must be used. Regency uses a gasket rope inspected at least once every two months during 7/8" (Part #846-570). A proper high temperature the heating season to determine if creosote build gasket adhesive is required.

  • Page 25: Catalytic Combustor Part#075-531

    Step 3: Engage the bypass mechanism and move to by-pass open position. And again observe the emission leaving the chimney. Significantly more smoke should be seen when the smoke is not routed through the combustor (by-pass open). Be careful not to confuse smoke with steam. I1500 Regency Wood Insert...
  • Page 26 9. Loosen bolts on catalyst retainer then, slide the catalyst retainer to the right to remove. 5. Remove the right and left side baffles (right side baffle shown below). 9. Pull down catalyst assembly to remove. Catalyst 10. Reverse steps to reinstall catalyst. Baffle bracket 26 | I1500 Regency Wood Insert...

  • Page 27: Secondary Air Tube Removal

    5. To reinstall or replace, first slide left side of tube into hole on left side air or Contact your local Regency Dealer. See warranty information at channel. Align tab on right side air channel with notch on right hand end of the back of this manual for details.
  • Page 28 NOTE: when cleaning chimney, remove tubes, baffles, retainer, flame shield and catalyst. After sweeping re-install. Diagram 14 Catalyst in square support 28 | I1500 Regency Wood Insert 920-051b 03.24.20...
  • Page 29 Alternatively, the catalyst may be removed so this can also be cleaned at the same time following the guide lines found in this manual. We highly recommend that the chimney cleaning be done by a professional as they will have the necessary tools such as a proper sized brush and special vacuum cleaner designed to deal with fine particles. I1500 Regency Wood Insert...

  • Page 30: Parts

    075-037 SS Smoke Deflector 075-097 Bypass Rod (Standard Flue Adaptor) 172-027 Bypass Rod (Offset Flue Adaptor) 911-096 120 Volt Power Cord 948-444 Regency Flame Logo Silver 911-186 Digital Monitor Probe 075-021 Firebox Floor Gasket 30 | I1500 Regency Wood Insert...
  • Page 31 MAIN ASSEMBLY See Catalyst Assembly in Manual under Parts List I1500 Regency Wood Insert...

  • Page 32: Brick Panels

    4.250 x 8.000 x 30 DEG BRICK 802-147 3.500 x 4.500 BRICK 802-152 2.000 x 9.000 BRICK 902-111 9.000 x 4.500 STANDARD BRICK RD-14289 4.500 x 7.000 BRICK RD-14288 4.250 x 7.000 BRICK ITEM PART NUMBER QTY. DESCRIPTION 32 | I1500 Regency Wood Insert...

  • Page 33: Catalytic Combustor Assembly

    Part # Description 075-101 Catalyst slide 075-102 Gasket bracket 075-104 Long shield bracket 936-236 Rope gasket 1/2" diameter 075-043 Rod lock 075-531 5.83 diameter combustor assembly 075-044 Cat cradle 075-105 Offset flame shield 075-103 Rod clip lock I1500 Regency Wood Insert...

  • Page 34: Faceplates

    Black Perimeter Trim Black Regular Faceplate N/S 171-572 Black Perimeter Trim Black Oversize Faceplate N/S 948-223 Regency Logo Plate N/S 171-526 Faceplate Mounting Brackets (Each) N/S 171-546 Faceplate Hardware Package *Not available as a replacement part. 34 | I1500 Regency Wood Insert...
  • Page 35 I1500 Regency Wood Insert...

  • Page 36: Warranty

    At all times FPI reserves the right to inspect reported complaints on location in the field claimed to be defective prior to processing or authorizing of any claim. Failure to allow this upon request will void the warranty. Revision Date: July 2019 Regency Wood Products Warranty 36 | I1500 Regency Wood Insert...
  • Page 37 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Revision Date: July 2019 Regency Wood Products Warranty I1500 Regency Wood Insert...
  • Page 38 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
  • Page 39 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
  • Page 41 All warranty claims must be sent to: Regency Fireplace Products By Authorized Regency Dealer * Prices subject to change. Regency reserves the right to reject any claim if it is determined the damage is a result of misuse, abuse or improper cleaning/ handling. I1500 Regency Wood Insert...
  • Page 42 42 | I1500 Regency Wood Insert...
  • Page 43 I1500 Regency Wood Insert...
  • Page 44 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Printed in Canada Regency is a trademark of FPI Fireplace Products International Ltd. © Copyright 2020, FPI Fireplace Products International Ltd. All rights reserved.
