1. DISASSEMBLY

1-1. REMOVAL OF COVER AND TB-1 BOARD
2
1. Surface cover
2. Drop-prevention cable
3. Hook
4. Lever lock
5. Two screws 2 x 6
6. Two screws 2 x 6
7. Cover pan left
8. Cover pan right
9. Spacer cabinet main
10. Screw 3 x 6
11. Holder bottom
12. Connector (CN942)
13. Fixer
14. Four screws 4 x 12
When assembling,
tighten the screws order.
(1
4 : Stamp of the
chassis base)
15. Turns
16. Screw 2 x 6
17. Three screws 2 x 4
18. Cover seftey wire
19. Mounting seftey wire
20. Two screws 2 x 6
21. TB-1 board
22. Connector (CN942)
23. Motor fan
24. Four damper fans
25. Screw 3 x 8
26. Washer V
27. Pipe
28. Lever lock
29. Screw 3 x 8
30. Washer V
31. Pipe
32. Lever lock
33. Screw 2 x 4
34. Spring lever
3
4
1
36
35
30
29
13
35. Screw 2 x 4
36. Spring lever
37. Four spacer sheets
38. Shield tape
39. Four spacers
40. Cabinet main
4
8. Cover pan right
8
15
6
38
39
32
31
37
9
22
20
12
11
10
-
-
4
7. Cover pan left
14
28
27 26
39
40
38
39
24
5
24
23
37
18
19
21
16
17
7
25
33
34
