1-4. REMOVAL OF ASSY, MOTOR
6
7
6
6
3
4
5
11
12
17
18
16
14
15
13
20. Connector (CN801)
21. Four damper fan motor
22. Three screws 2 x 4
23. Three screws 2 x 4
24. Connector (CN705)
25. Three screws 2 x 4
26. Holder, cable
27. Assy, shield, wire
28. Three screws 2 x 4
29. Assy,gear
30. Assy, holder cam unit
8
9
2
1
17
16
20
24
30
29
28
-
-
6
1. Two screws 3 x 6
2. Assy,motor step
3. Two screws 3 x 6
4. Two screws 3 x 6
5. Assy,motor step
6. Three screws 2 x 6
When assembling, tighten the
screws order. A
7. Earth,shaft
8. Housing, bearing
9. Bearing
10. Chassis pan
11. Three screws 2 x 4
12. Assy,gear
13. Three screws 3 x 10
14. Assy,term slip ring
15. Shield tate slip
16. Six screws 2 x 5
17. Shield,sensor pan
18. Chassis base
19. Motor fan DC
19
21
21
22
C
25
27
22
22
26
23
